Description and function
Technical data
Cable length
PLR interface
Interface
Cable length
Table 3: Technical data
5.3 Standards
The CIF modules with BACnet protocol comply with ISO 16484-5:2017. Details can be
found in the PICS Statement (English).
The CANopen CIF modules correspond to the following CAN in Automation standards:
ƒ
The LON CIF modules correspond to the following LonMark International standards:
ƒ
ƒ
ƒ
ƒ
ƒ
The Modbus RTU CIF modules correspond to the MODBUS APPLICATION PROTOCOL
SPECIFICATION V1.1 and Modbus over Serial Line protocol V1.02 in the module with
Modbus RTU, available at modbus.org.
6 Description and function
The CIF modules enhance the device with communication interfaces for various
standards.
For more information visit www.wilo.de/automation (German), www.wilo.com/auto-
mation (English).
7 Installation and electrical connection
Electrical connection may only be carried out by a qualified electrician and in accord-
ance with the applicable regulations!
Installation and operating instructions Wilo-CIF-Module
CiA 301 Version 4.2.0: CANopen application layer and communication profile
Application Layer Interoperability Guidelines Version 3.2
Layers 1-6 Interoperability Guidelines Version 3.2
node object 0000_20
pump controller object 8120_10
Resource Files Version 13.04
900 m with bus topology (with terminator) and
max. 3 m long spur lines
450 m with free topology, with max. 250 m
between 2 inter-communicating nodes
Current loops (≅ 5 mA)
²
200 m (max. / 0.5 mm )
