Assembly
This manual gives instructions on the correct assembly
and safe use of your machine.It is important that you read
these instructions carefully .When fully assembled the
machine weighs approximately 10kg. If necessary, obtain
assistance to remove from packaging, Take care when
carrying the mower to the lawn , as the blades are sharp.
Delivered Items
Carefully remove the machine from its packaging and
check that you have all the following items:
Lawnmower with handle assembly
• 2 Handles bottom
• 2 Bolts
• 2 Knob module (Thumb screw)
• 3 Screws
• Grass box
• 1 Cable clip
Assembly (fi g. A)
Important! Before you assemble the lawn mo-
wer, check the accessories according above
information, make sure the accessories are
completed.
1. Insert the lower handles 6 into the holes provided in
the deck, secure with the screws (A1).
2. Attach the cable strain relief 4 to the upper handle
3 (A2).
3. Attach the upper handle 3 with bolts and knob module
5 to the lower handles 6 (A3).
Note: Ensure that the cable clips 12 are used to fi x the
cable to the handle
Attach cable to cable strain relief 4 ensuring that suffi cient
cable slack is available. (not for GB models)
Ensure cables are not trapped when folding/unfolding top
handles. Do not drop the handles.
Assembly of Grass box (fi g. B)
1. Assemble the grip onto the upper cover of the catcher
(B1). Screw the handle tight and assemble the lower
two halves (B2)
2. Slide the grass box tongue into the slots in the grass
box lower until it clicks securely into position. (B2)
3. Starting at the rear of the grass box, locate the grass
box cover into the grass box by sligning the clips. En-
sure all clips are correctly located. (B3 + B4)
4. Fitting assembled grass box to lawn mower (B5):
a) Lift the safety guard 8 (B5-a).
b) Make sure the discharge chute is clean and free
from debris.
c) Locate fully assembled grass box 7 onto location
points at the rear of the deck as illustrated (B5-b).
d) Locate safety fl ap onto the top of the grass box.
Ensure the grass box is easy located.
GB | Operating Instructions
Note: For non grass collection the mower can be used
without the grass box in position, with the safety guard 8
in the down position.

Adjusting the Cutting Height

Confi rm lock and simultaneously set the required height
by either pulling or pressing on the lever 13. When relea-
sing the lock, the setting selected snaps into place.
There are fi ve heights of cut on this product.
NOTE
A medium height of cut is recommended for most lawns.
The quality of your mowing will suff er and collection will
be poor if you cut too low.
HEIGHT OF CUT
Low
Low to Medium
Medium
Medium to High
High

Starting and Stopping

Start:
• Press and hold the safety button 2. Squeeze the
• Release the safety button 2.
Stopp:
• Release the switch lever 1.
Warning: Blade continues to rotate after the machine
is switch off . Wait until all machine components have
completely stopped before touching them.
Mowing
6
Warning: release switch lever 1 and wait until the
motor stops before adjusting height. The blades
continue to rotate for a few seconds after the ma-
chine is switched off , a rotating blade can cause
injury.
WHEELS POSITION
Make sure the blade stopped rotating before
switching "on" again.
Do not rapidly switch on and off .
switch lever 1 towards the handle (D).
(fi g. E)
(fi g. C)
25 mm
36 mm
47 mm
58 mm
70 mm
(fi g. D)
