LoRaWAN 863-870 ANALOG - Guide utilisateur / User guide version V2.0.1
Description of the frame:
• Byte 2: register 300, periodicity of the Keep Alive frame, expressed in tens of minutes
• Byte 3: register 301, periodicity of the transmission, expressed in tens of minutes
• Byte 4: register 320, configuration of the channel A sensor
• Byte 5: register 321, configuration of the events on channel A
• Byte 6: register 322, configuration of the channel B sensor
• Byte 7: register 323, configuration of the events on channel B
• Byte 8: register 306, product mode (Park, Standard (production), Test or REPLI)
FR
In the example in grey this gives:
• Byte 2=0x48: register 300, Keep Alive frame issued every 12 hours
• Byte 3=0x00: register 301, event mode
• Byte 4=0x02: register 320, channel A configured for a 4-20mA sensor
• Byte 5=0x03: register 321:
o Detection of high and low thresholds on channel A
EN
o Detection of event on disabled digital input
o No waiting period
• Byte 6=0x01: register 322, channel B configured for a 0-10V sensor
• Byte 7=0x02: register 323:
o Detection of high and low thresholds only
o Detection of event disabled digital input
o No waiting period
• Byte 8=0x01: register 306, Production mode in progress
WARNING : if none of the channels is configured (value = None in registers 320 and 322), the product will send the configuration frame 0x10
periodically (period defined by register 300)
0
1
Code
Status
0x11
Cf Status
0x11
0x42
Description of the frame:
• Bytes 2 to 4: register 324, high threshold of channel A sensor
• Bytes 5 to 7: register 325, high hysteresis of channel A sensor
In the example in grey this gives:
• Bytes 2 to 4=0x124F80=1,200,000 in decimal: register 324, the value of the high threshold for channel A is: 1,200,000x10=12,000,-
000nA i.e.12mA
• Bytes 5 to 7=0x0186A0=100,000 in decimal: register 325, the value of the high hysteresis for channel A is: 100,000x10=1,000,000nA i.e.
1mA
0
1
Code
Status
0x12
Cf Status
0x12
0x42
Description of the frame:
• Bytes 2 to 4: register 326, low threshold of the channel A sensor
• Bytes 5 to 7: register 327, low hysteresis of the channel A sensor
2
3
PAYLOAD
S324
0x124F80
2
3
S326
0x0927C0
4
5
6
S325
0x0186A0
4
5
6
PAYLOAD
S327
0x0186A0
7
8
9
X
X
7
8
9
X
X
10
X
10
X
Page
74
of 90
