ADEUNIS ARF8190BA Guide Utilisateur page 71

LoRaWAN 863-870 ANALOG - Guide utilisateur / User guide version V2.0.1
S216 LORA APP-KEY (first part – MSB)
S217 LORA APP-KEY (second part – MID MSB)
S218 LORA APP-KEY (third part – MID LSB)
S219 LORA APP-KEY (fourth part – LSB)
S220 LoRaWAN Options
S221 Activation mode
S222 LORA NWK_SKEY (first part – MSB)
S223 LORA NWK_SKEY (second part - MID MSB)
S224 LORA NWK_SKEY (third part - MID LSB)
S225 LORA NWK_SKEY (fourth part – LSB)
S226 LORA APP_SKEY (first part – MSB)
S227 LORA APP_SKEY (second part - MID MSB)
S228 LORA APP_SKEY (third part - MID LSB)
S229 LORA APP_SKEY (fourth part – LSB)
S250 Configuration Channel 0
S251 Configuration Channel 1
S252 Configuration Channel 2
S253 Configuration Channel 3
S254 Configuration Channel 4
Hexadecimal Default: 0
Key coded on 32 octet characters. Each of the 4 regis-
Hexadecimal
ters contains 8 characters.
Hexadecimal
Used during JOIN phase in OTAA mode
Hexadecimal
For example:
APP-KEY = 0018B244 41524632 0018B200
00000912
• S216 = 0018B244
• S217= 41524632
• S218 = 0018B200
• S219 = 00000912
Hexadecimal Default: 5
Bit 0: Activation of the ADR ON(1)/OFF(0)
Bit 1: Reserved
Bit 2: DUTY CYCLE ON(1)/DUTY CYCLE OFF(0)
Bit 3 to 7: Reserved
IMPORTANT NOTE:
Deactivation of the duty cycle may result in the use of the
product in a way that is not compliant with the conditions
of use of the frequency band therefore is a violation of the
regulations in force.
In the case of Duty Cycle deactivation, responsibility is
transferred to the user.
Decimal Default: 1
Choice: (see NOTE1 after the table)
• 0: ABP
• 1: OTAA
Hexadecimal Default: 0
Parameter encoded on 16 bytes. Each of the 4 registers
Hexadecimal
contains 4 characters.
Hexadecimal
Hexadecimal
Hexadecimal Default: 0
Parameter encoded on 16 bytes. Each of the 4 registers
Hexadecimal
contains 4 characters.
Hexadecimal
Hexadecimal
Decimal Default: 1
Mandatory LoRaWAN operating channel
Do not change this value
Decimal Default: 1 (868); 0 (915)
Mandatory LoRaWAN operating channel
Do not change this value
Decimal Default: 1
Mandatory LoRaWAN operating channel
Do not change this value
Decimal Default: 0 (868); 1 (915)
0: Canal deactivated
Other: User Configuration (NOTE2)
Decimal Default: 0
0: Canal deactivated
Other: User Configuration (NOTE2)
FR
EN
Page 71 of 90
