CARATTERISTICHE TECNICHE

GENERALI
Canali........................................................................................(vedi tabella bande)
Gamma di frequenza* ...................................................26.565 - 27.99125 MHz
Ciclo di utilizzo (% su 1 ora) ...............................TX 5%; RX 5%; Stand-by 90%
Controllo di frequenza ................................................................................. a PLL
Temperatura ........................................................................................ -10°/+55° C
Tensione di alimentazione ..............................................DC 12.6 V - DC ±10%
Dimensione ............................................................ 180 (L)x50 (H)x150 (P) mm
Peso .....................................................................................................................1 kg
RICEVITORE
Sistema ricevente .....................................supereterodina a doppia conversione
Frequenza intermedia .............................................................. I° IF: 10.695 MHz
......................................................................................................... II° IF: 455 KHz
Sensibilità ..........................................................0.5µV per 20 dB SINAD in FM
............................................................................0.5µV per 20 dB SINAD in AM
Potenza d' uscita audio @10% THD .......................................2.0 W @ 8 Ohm
Distorsione audio ............................................................. meno dell'8% @ 1 KHz
Reiezione alle immagini .................................................................................65 dB
Selettività sul canale ......................................................................................65 dB
Rapporto segnale disturbo ........................................................................... 45 dB
Assorbimento all'attesa ............................................................................. 250mA
TRASMETTITORE
Potenza d'uscita ........................................................................................4W max
Modulazione ........................................................................... AM: da 85% a 95%
.......................................................................................... FM: 1,8 KHz ± 0,2 KHz
Frequenza di risposta .....................................................................300 Hz/3 KHz
Impedenza d' uscita ........................................................RF 50 Ohm sbilanciato
Rapporto segnale disturbo ................................................................. 40 dB MIN
Corrente assorbita .....................................................................................1100mA
* (considerando tutte le bande di frequenza europee approvate)
6
Le specifiche sono soggette a modifiche senza preavviso.
Un dispositivo di sezionamento adatto deve essere previsto nell'impianto elettrico. Tale dispo-
sitivo deve disconnettere entrambi i poli simultaneamente.
INDEX
Introduction ..................................................................................................... Pag. 1
Function and location of the controls ......................................................... Pag. 2
Installation ........................................................................................................ Pag.4
Power supply.................................................................................................... Pag.4
Installing an antenna ....................................................................................... Pag.4
How to operate with your transceiver .......................................................... Pag.5
Frequency band selection .............................................................................. Pag.5
Frequency band chart .................................................................................... Pag.5
Technical specifications .................................................................................. Pag.6
Your represents the state-of-the art in high-tech
ALAN 48 PLUS MULTI B
engineering. Designed for the Citizen Band Mobile operation, this compact
package is big in performance. It is a quality piece of electronic equipment,
skillfully constructed with the finest components. The circuitry is all a solid-
state, mounted on rugged printed circuit boards. It is designed for many years
of reliable, trouble-free performance.The night-light buttons allow the night
use.Your has a built Channel Phase-Locked Loop
ALAN 48 PLUS MULTI B
synthesizer circuit.
The PLL circuit achieves a new technique for generating all the required
frequencies with fewer crystals. The result is much tighter frequency control
and superior reliability.
