Charging Characteristic Curve; Assembly - Calira Module B Mode D'emploi

Use: For charging batteries with a rated voltage of 12 volts and
a capacity of:
55–160 Ah for the MES 250-(1-4) / Module A
90-270 Ah for the MES 400-(1-4) / Module A
Housing: Aluminium, bright, ventilated
Length: 340 mm
Width: 130 mm
Height: 100 mm
Weight: 1.3 kg (13 N)
Charging characteristic
curve
HL = Main charging phase
NL = Post charging phase
EL = Holding charge phase
# $% & $ $ '

Assembly

Safety instructions
'
, !
Connecting the device to the power supply must comply with the
applicable national installation regulations.
This device contains components that may generate electric arcing and
sparks. Therefore when operating the device in a garage or a similar
location, it must be contained in a room or housing designed for this
purpose!
