Mode Switch and Mode Keys

The mode switch can be operated by inserting one of the two supplied mode keys - manager (MA) and operator
(OP) keys. These keys can be inserted or removed only in the "REG" or "
Manager key (MA)
Operator key (OP)
4

Keyboard

Keyboard layout
The small characters on the bottom or lower right in each key indicates functions or characters
which can be used for character entries for text programming. For details, refer to page 35.
Key names
Receipt paper feed key
RECEIPT
Journal paper feed key
JOURNAL
Received-on account key
RA
RCPT
Receipt print/Paid-out key
/PO
Void key
ESC Escape key
Percent 1 and 2 keys
%1 %2
Refund key
RF
Discount key
Page 5
The mode switch has these settings:
: This mode locks all register operations. (AC power turns off.)
No change occurs to register data.
OP X/Z: To take individual clerk X or Z reports, and to take flash reports.
It can be used to toggle receipt state "ON" and "OFF" by pressing
R
the
REG: For entering sales.
PGM: To program various items.
: Enters into the void mode. This mode allows correction after
finalizing a transaction.
MGR: For manager's entries. The manager can use this mode for an
override entry.
X1/Z1: To take the X/Z report for various daily totals
X2/Z2: To take the X/Z report for periodic (weekly or monthly)
consolidation
Multiplication key
• Decimal point key
Clear key
CL
00 0 ~ 9
PLU
PLU/Subdepartment key
/SUB
DEPT
Department code entry key
#
DEPT
Department shift key
SHIFT
Clerk code entry key
CLK#
21 40
~ Department keys
1 20
" position.
key.
25 30 35 40
20
5 10 15
24 29 34 39
9 14 19
4
33 38
23 28
3 8 13 18
22 27 32 37
17
2 7 12
21 26 31 36
1 6 11 16
AUTO AUTO
1 2
Foreign currency
EX
exchange key
Value added tax key
VAT
Numeric keys
CR1 CR2
CH1 CH2
#/TM/ST
TL / NS
Automatic sequence keys
Credit 1 and 2 keys
Cheque 1 and 2 keys
Non-add code/Time display
/Subtotal key
Total/No sale key
