OFFSET SIZE UNIT
BYTE BYTE
28 1 Sccm
29 1
In order to donít overload the controllerís internal serial link, following precautions are taken:
•
The parameters are written from the gateway to the controller only when their value changes.
•
The parameters are never read back from the controller to the interface. The controllerís response at the
write command (ACK, NACK, etc) is used to establish if the writing succeed or not.
RANGE
RES
B4 ñ Verify Line Select
(the auto voltage selection mismatch the real input voltage)
B3 ñ Power Fail
(internal circuitry failure)
B2 ñ Controller Over-Temperature
(ìController Power Section Temperatureî or ìController CPU Section Tem-
perature" are over the limit)
B1 - Pump Over-temperature
(ìPump Bearing Temperatureî or ìPump Body Temperatureî are over the
limit)
B0 ñ Check Connection To Pump
(the connection between controller and pump missing)
Flow Meter Reading
(Specific option, not available on standard models)
- B0 ñ Start/Stop Status
0 = Stop
1 = Start
B1 ñ Low Speed Status
(Read the ìLow Speedî function status (Out Buff byte-0 B6))
0 = off (the ìtarget speedî (In Buff byte-8) isî high speedî (Out. Buff.
byte-1))
1 = on (the ìtarget speedî (In Buff byte-8) is ìlow speedî (Out. Buff.
byte-3))
B2 ñ Soft Start Status
0 = on
1 = off
(this function is active at first pump run-up and canít be deactivated by the
user, after first run-up activate this function only if the pump has been
stopped for at least3 months; this procedure will take 1h)
B3 ñ Vent Valve Status
0 = close
1 = open
B4 ñ Purge Valve Status
0 = close
1 = open
B5 ñ Set Point Status
0 = open
1 = closed
B6 ñ Flow meter Alarm Status
Specific option, not available on standard models
B7 ñ Not Used
DESCRIPTION
NOTE
91
TECHNICAL INFORMATION
SERIAL
87-900-968-01(C)
