5. Connect the supplied speaker
cables to the back of Plasma
Display.
• Connect the cables correctly with respect to the
polarity of the Plasma Display and the speaker
terminals, that is, cable to
cable to terminals. To do so, connect the
cable with the gray line to the
the white cable to the
White
Gray line
Black
Red
Speaker terminal
Caution
• Be sure to turn the connected devices off and remove
the power cord from the wall outlet beforehand when
changing the connection or installation method.
• If you insert the speaker cable too far so that the insulation
is touching the speaker terminal, you may not get any
sound. Please insert it with showing the copper wire.
• Check if the end of the speaker cables are securely
connected to the terminals by slightly tugging on the cable
after making connections. Loose connections may result
in sound dropouts or noise.
• If there is a short in the
exposed lead wire, excessive load may be applied to the
Plasma Display, resulting in interrupted operation or
malfunction.
• Incorrect connections of the speaker cable to the right or
left of the Plasma Display terminals with respect to the
polarity may result in insufficient stereo sound effects,
delivering poor bass sounds or unstable sound image.
• Bundle the code without pulling the cord.
terminals and
terminals and
terminals.
White
Gray line
Red
Speaker terminal
Speaker cable
and cables caused by an
Red
Black
Gray line
• Press the lever and insert the end of the
cable.
• When you release the lever, it clamps onto
the speaker cable.
Speaker terminal
English
6. Connect the other end
of the speaker cables
to the speaker.
• Connect the cables correctly with
respect to the polarity of the Plasma
Display and the speaker terminals,
that is, cable to terminals and
cable to terminals. To do so,
connect the cable with the gray line
to the terminals and the white
cable to the terminals.
Lever
