deck to prevent the blade from turning.
4. Loosen the blade nut by turning it counterclockwise
(as viewed from bottom of mower) using a 15 mm
wrench or socket (not provided).
5. Remove the blade nut, spacer, blade insulator, and
blade.
6. Make certain the blade holder is pushed completely
against the motor shaft.
7. Place the new blade on the shaft. Ensure blade
is properly seated with shaft going through center
blade hole and the two blade posts inserted into their
respective holes on the blade. Make sure it is installed
with the curved ends pointing up toward the mower
deck and not down toward the ground. When seated
properly, the blade should be flat against the blade
holder.
8. Replace the blade insulator and spacer, then thread
the blade nut on the shaft and finger tighten.
NOTE: Make certain all parts are replaced in the exact
order in which they were removed.
9. Torque the blade nut down clockwise using a torque
wrench (not provided) to ensure the bolt is properly
tightened. The recommended torque for the blade nut
is 62.5~71.5 kgfcm (350-400 in.-lb.).

REPLACING THE WHEELS

See figure 11.
To ensure smooth operation of wheels, the wheel
assembly should be cleaned before storage.
To replace a front wheel:
1. Remove the covers on the rear wheel.
2. Remove the opening pins and the washers.
3. Remove the wheel and replace with new wheel.
4. Replace the washers, pins and the wheel covers.
To replace a rear wheel:
1. Remove the covers on the rear wheel.
2. Remove the opening pins.
3. Remove the wheel and replace with new wheel.
4. Replace the pins and the wheel covers.
