MOUNTING THE CAMERA

Pull the supplied mounting strap through the eyelet (21) on camera rear side and mount the camera to a tree, pole or any suitable object. Do not
fi x the belt fi nally at this stage. The optimum distance to the object is between 3 to 10 meters. Larger distances are also possible, however with
less reliability of motion sensor. We recommend to direct the camera fi rst (refer to capture 11) and to take a few test shots before fi xing the
camera fi nally.
Our optional accessories such as the patented DÖRR holding fi xture in combination with the DÖRR universal adapter are designed for fast and
easy mounting of the camera at a tree, wall or other object. The camera clicks into the holding fi xture and is fi rmly held in place. The camera can
be removed easily for a quick change of place of action. The ball head with fi xing screw ensure a fl exible direction of the camera. The fi xture is
rotatable by 360° and swivels up to 30° in all directions.
Ask your specialised dealer for:
DÖRR Holding Fixture for SnapShopt Multi
DÖRR UNI-1 Universal Adapter for Holding Fixture
With an additional cable lock (optional) pulled through the specifi c eyelets (20) on camera rear side, your camera will be secured safely against
theft.
11 |

ORIENTATION OF THE CAMERA

To achieve perfect pictures, the camera must be oriented properly:
1. Fix the camera at a height of 0,75m to 1,00m and slightly tilt it forward. The camera lens (4) should now point to the position, where the object
of photography or fi lming is expected.
2. Move the slide control (12) to the position SETUP and close the camera housing. When you move in front of camera the LED indicator (2)
is fl ashing red and the motion detector is active. The red LED (2) will fl ash as long as you are moving within the motion detectors range.
3. We suggest that you now take a test picture. Move the slide control (12) to position ON and close the camera housing.
After approx. 5s is the camera ready to detect (while camera is preparing the red LED (2) is fl ashing).
4. Move with normal speed through detection area. The camera releases and you can view the image on the monitor as described in capture
08 | PLAYBACK. The camera should be oriented in a way that the object will appear in the centre of the picture. You may have to re-adjust
the camera and take another test shot.
TIP: To change the camera angle you may use e.g. a small wooden wedge and clamp it between camera and trunk.
5. Once the camera position is correct, the mounting belt can be tightened to hold the camera fi rmly.
12 |

START SURVEILLANCE

In order to get the camera ready to work, move the slide control (12) to the position ON. Then close the camera housing. After approx. 5 seconds,
the camera will be active. In case of movements detected, it takes pictures according to your settings.
Item no. 204490
Item no. 204495
