The instructions given in this manual describe the operation and maintenance of MOD. XX, MOD. XX-PH and MOD. XX+.
electrolysis systems. For optimum performance of the salt electrolysis systems, we recommend you to follow the instructions
given below:

1 General features:

When the salt electrolysis system is installed, a quantity of salt must be dissolved into the swimming pool water. This salty water then
passes through the electrolysis cell that is located in the plant room. The salt electrolysis system consists of two elements: an
electrolysis cell and a power supply. The electrolysis cell contains a quantity of titanium plates (electrodes) and when a weak
electrical current is passed through the plates inside the electrolysis cell, there is chlorine production. In addition the electrode set has
a temperature probe to measure the water temperature.
Maintaining a level of chlorine in swimming pool water keeps the water sanitised and healthy to swim in. The salt electrolysis system
will manufacture chlorine whenever the pool circulation system (pump and filter) is working.
The power supply is provided with various safety devices, which are activated in case of irregular operation of the system, as well as a
microprocessor driven control system. It also indicates the approximate concentration of salt in the water.
The salt electrolysis systems have an automatic cleaning system that avoids scale formation on the electrodes. Moreover, MOD.
XX+ systems include a built-in pH/ORP controller.
2 Safety warnings and recommendations:
-The equipment should be assembled and handled by truly qualified people.
-Current electrical and accident prevention regulations should be followed.
-Under no circumstances will the manufacturer be held responsible for the assembly, installation or start-up, nor any handling or
fitting of components unless they are carried out on its premises.
-The salt electrolysis systems operate at 230VAC, 50/60 Hz. Do not attempt to alter the system to operate at a different voltage.
-Check that all the electrical connectors are well tightened to avoid false contacts and their consequent overheating.
-This device is equipped with a cable that has a ground conductor. The equipment must be powered from a residual current device,
which does not exceed 30mA (RDC). The equipment must be electrically grounded.
-Before installing or replacing any component, disconnect the equipment from the mains, and use exclusively spare parts supplied by
the manufacturer.
-If the power cable is damaged, it must be replaced by the manufacturer, its after-sales service or by similar qualified personnel in
order to avoid a danger.
-Taking into account the fact that the equipment produces heat, it must be installed in places with sufficient ventilation. Fan openings
should be kept free of any element that could obstruct them. The equipment should not be installed near flammable materials.
-The salt electrolysis systems have not be installed in places susceptible to flooding.
-This appliancecan be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge and they have been given sipervision or instruction concerning use of the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Warning: For the electrical connection it is necessary to incorporate a disconnector switch that ensures the omnipolar cut, directly
connected to the power terminals and must have a contact separation at all its poles, which provides total disconnection under
overvoltage conditions of category III, in an area that complies with the site safety requirements.
