EN
Standard working voltage
230V AC – 50/60 Hz.
Cable: 3 x 1.0 mm2, leng. 2 m.
MOD. 7 0.2 A
MOD. 12 0.4 A
MOD. 21 0.4 A
MOD. 30 0.8 A
MOD. 40 0.9 A
Fuse
MOD. 7 1 A T (5x20 mm)
MOD. 12 2 A T (5x20 mm)
MOD. 21 2 A T (5x20 mm)
MOD. 30 3.15 A T (5x20 mm)
MOD. 40 4 A T (5x20 mm)
Output voltage
Cable 3 x 2.5 mm2, long. 2 m.
MOD. 7 10.5 VDC / 3.5 A
MOD. 12 10.5 VDC / 6.0 A
MOD. 21 23.0 VDC / 3.5 A
MOD. 30 20.0 VDC / 6.0 A
MOD. 40 24.0 VDC / 6.5 A
Production
MOD. 7 6 – 7 g./h.
MOD. 12 10 – 12 g./h.
MOD. 21 17 – 21 g./h.
MOD. 30 24 - 30 g./h.
MOD. 40 31 - 40 g./h.
Minimum recirculation flow
MOD. 7 1 m3/h.
MOD. 12 2 m3/h.
MOD. 21 3 m3/h.
MOD. 30 5 m3/h.
MOD. 40 6 m3/h.
Electrode number
MOD. 7 3
MOD. 12 5
MOD. 21 7
MOD. 30 11
MOD. 40 13
Net weight (packaging included)
MOD. 7 9 Kg.
MOD. 12 11 Kg.
MOD. 21 13 Kg.
MOD. 30 15 Kg.
MOD. 40 17 Kg.
System control
- Microprocessor.
- Touch control buttons and operating indicator leds.
- Control I/O: 3 voltage-free contact type inputs for automatic cover status,
residual ORP / chlorine controller and external flow.
- Cell output: production control (10 discrete levels).
- Salinity / Temperature range:
3 - 12 g/l. / +15 - 40ºC
- Built-in pH/ORP controller (pH and pH/ORP only models).
- Non-isolated MODBUS
- Output 220V / 0.5A pH pump control (pH and pH/ORP only models).
Self-cleaning
Automatic polarity reversal
Working temperature
From 0ºC (32ºF) to + 50ºC (125ºF)
Cooling: natural convection
Material
- Power supply
ABS
- Electrolysis cell / Sensor holder
Methacrylate derivative. Transparent
pH Sensor
Body: plastic (blue)
Range 0 -12 pH
Solid electrolyte
ORP sensor
Body: plastic (red)
Range 0 – 1000 mV
Solid electrolyte
