Wilo SCP Série Notice De Montage Et De Mise En Service page 71

Table for Gland Packing Details For SCP pumps
SCP 80-360 DS
SCP 100-270 HA
SCP 100-280 HA
SCP 100-360 HA
SCP 100-400 HA
SCP 100-410 DS
SCP 125-290 HA
SCP 125-330 HA
SCP 125-440 HA
SCP 125-470 HA
SCP 125-460 DS
SCP 150-290 HA
SCP 150-390 HA
SCP 150-350 HA
SCP 150-440 HA
SCP 150-580 HA
SCP 150-530 HA
SCP 150-460 DS
SCP 200-310 HA
SCP 200-320 HA
SCP 200-370 HA
SCP 200-360 HB
9.5.3 Reassembly of rotating element (Mechanical
seal version pump)
Procedure for rotor assembly for mechanical seal
pump is similar up to assembly of stuffing box
bush(11)
Reassembly of mechanical seal is as follows:
• Extreme cleanliness must be observed during ins-
tallation, and damage to the seal faces and moun-
ting rings must be avoided
• Place the adjusting ring of mechanical seal at its
pre marked position
• Place the grab screw(13) at its position on the
adjusting ring, but tight it yet
• The O-rings may be oiled to reduce friction, during
installation of the seal. EP-rubber O-rings should
not come into contact with oil or grease; In this
case lubrication with glycerine or water is recom-
mended.
• Never cover the sliding faces with a lubricant as
they must be assembled completely dry, clean and
dust-free.
• When pressing in stationery seals, make sure that
the pressure distribution is uniform. The O-ring
must be fitted using water or alcohol only.
• Crowned drive pins must be replaced whenever
the seal is dismantled. During insertion of the sta-
tionary seats, especially those of special carbon,
care must be taken to exert pressure evenly.
• Now check the distance of seal as shown in the
figure and adjust its value as per values given table
• For rest parts follow the above explained proce-
dure as per gland pack version pump
Installation and operating instructions Wilo-SCP
10 4
14 3
14 3
14 3
14 3
10 14
16 3
16 3
16 3
17.5 3
12 6
16 3
17.5 3
17.5 3
17.5 3
20 3
20 3
12 5
17.5 3
17.5 3
17.5 3
17.5 3
SCP 250-360 HA 20
SCP 250-450 HA 22
SCP 250-570 HA 22
SCP 250-700 DV 20
SCP 250-740 DV 20
SCP 300-330 HB 20
SCP 300-380 HA 20
SCP 300-400 HA 20
SCP 300-490 HA 22
SCP 300-570 HA 22
SCP 300-660 DV 20
SCP 350-500 HA 22
SCP 350-470 HA 22
SCP 400-540 HA 22
SCP 400-480 HA 22
SCP 400-550 HA 20
SCP 400-710 HA 20
SCP 400-660 DV 20
Location of mechanical seal of shaft
1) Pump casing
2) Stationary seat
3) Stationary seat
4) Gland plate
5) O-ring
6) Shaft
X. Mechanical seal
1.6 Abutment ring
1.7 Abutment ring fixing screw
English
3
3
3
5
5
3
3
3
3
3
5
3
3
3
3
5
5
5
