Restarting Protection
The restarting protection feature prevents uncontrolled re-
starting of the machine after an interruption in the power sup-
ply.
To restart the operation, switch the On/Off switch 2 to the
Off position and start the machine again.

Working Advice

 Before any work on the power tool, remove the battery.
 Wait until the machine has come to a standstill before
placing it down.
Sanding Surfaces
Switch the machine on, place it with the complete sanding
surface on the surface to be worked and move the machine
with moderate pressure over the workpiece.
The removal capacity and the sanding pattern are mainly de-
termined by the selection of the sanding sheet, the preselect-
ed orbital stroke rate and the applied pressure.
Only flawless sanding sheets achieve good sanding capacity
and extend the service life of the machine.
Pay attention to apply uniform sanding pressure; this increas-
es the working life of the sanding sheets.
Intensifiying the sanding pressure does not lead to an in-
crease of the sanding capacity, but to increased wear of the
machine and the sanding sheet.
A sanding sheet that has been used for metal should not be
used for other materials.
Use only original Bosch sanding accessories.
Rough Sanding
Attach a sanding sheet with coarse grain.
Apply only light pressure to the machine so that it runs at a
higher stroke rate and high material removal is achieved.
Fine Sanding
Attach a sanding sheet with fine grain.
By lightly varying the application pressure or changing the or-
bital stroke rate, the sanding plate stroke rate can be reduced
whereby the orbital action is maintained.
With moderate pressure, move the machine in a circular pat-
tern or alternately in lengthwise and crosswise directions
over the workpiece. Do not tilt the machine to avoid sanding
through the workpiece (e. g. when sanding veneer).
After finishing the working procedure, switch the power tool
off.
Polishing
For the polishing of weathered paint or buffing out scratches
(e.g., acrylic glass), the machine can be equipped with appro-
priate polishing accessories such as lamb's wool bonnet, pol-
ishing felt or sponge (accessories).
Select a low orbital stroke rate (level 1 – 4) when polishing in
order to avoid heating up the surface excessively.
Apply the polish onto a somewhat smaller surface than you in-
tend to polish. Work the polishing agent in with a suitable pol-
ishing tool applying it crosswise or with circular motion and
moderate pressure.
Bosch Power Tools
Do not allow the polishing agent to dry out on the surface, oth-
erwise the surface can become damaged. Do not subject the
surface to be polished to direct sunlight.
Clean the polishing accessories regularly to ensure good pol-
ishing results. Wash out polishing accessories with a mild de-
tergent and warm water; do not use paint thinner.
Application Table
The data in the following table are recommended values.
The most favourable combination for working is best deter-
mined by practical testing.
Roughening varnish
Touching up varnish
Removing varnish
Softwood
Hardwood
Veneer
Aluminium
Steel
Derusting steel
Stainless steel
Masonry, stone
Recommendations for Optimal Handling of the Battery
Protect the battery against moisture and water.
Store the battery only within a temperature range between
–20 °C and 50 °C. As an example, do not leave the battery in
the car in summer.
Occasionally clean the venting slots of the battery using a soft,
clean and dry brush.
A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.
Observe the notes for disposal.

Maintenance and Service

Maintenance and Cleaning

 Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating
the On/Off switch.
 For safe and proper working, always keep the machine
and ventilation slots clean.
When the battery is no longer operative, please refer to an au-
thorised after-sales service agent for Bosch power tools.
English | 17
180/240 2/3
120/240 4/5
40/60 5
40/240 5/6
60/240 5/6
180/240 2–4
80/240 4/5
40/240 5
40/120 6
80/240 5
80/240 5/6
1 609 92A 2LK | (12.8.16)
