Operation Instructions - TJEP RC20 Rod Cutter Manuel D'utilisation Et D'instructions

10 mm to 20 mm grade 60 (420MPa) re-bar (reinforcing bars), up to 13 mm I.D pipe, 20
mm O.D. copper water pipe, 20 mm O.D. tubing, 13 mm conduit, 20 mm square steel tub-
ing & bar, and up to 20 mm O.D. all-threaded or coil rod.
Rules of Use and Storage - To use the tool to its fullest performance, the user is required
to be fully familiar with the saw itself, the cutting blades, and storage procedures upon
completion of work.
Specification
The power tool is a multipurpose saw with an enclosed guard and flush cutting capabili-
ties. The specifications of the main unit are as follows.
Standard Blade: (Best for Ferrous Metals)
Supplied with (2) each 110 mm Blade diameter × 1.6 mm thickness, 24 teeth with laser
welded flange for mounting to TJEP RC20 ROD Cutter spindle. The maximum blade RPM
is 2000.
Operation
Checking and Preparation of Working Environment: Check the following before using the
TJEP RC20 Rod Cutter. Always observe the instructions and prohibited items.
Checking of weather conditions, do not use in the rain or snow:
!DANGER: TJEP RC20 Rod Cutter is not a waterproof power tool. If it be-
comes wet, the power source system may become faulty or the operator
may get an electric shock. Therefore, when it is raining or snowing, never
operate this saw outdoors, on top of buildings or under roofs where rain or
snow enters freely. Do not use where water accumulates or where water
splashes.

Operation Instructions

Adjust the rear handle position to comfortably grip the tool. (The rear handle changes
position with the button located on the top of the handle.) Locate the front handle in the
mounting hole that provides the best grip. To operate the trigger, depress the trigger lock
button (on the side of the tool) and then pull the trigger to start the saw. Start the saw
before cutting and then apply a light pressure moving forward through the cut.
!DANGER: Electric Shock Hazard. Ignoring this warning may lead to
death or serious injury. When raining or snowing, do not operate outdoors
or indoors where rain or snow enters freely or in extreme temperatures.
Do not use under high temperature and humidity or extremely cold temperature condi-
tions. The tool is designed for use under an allowable environmental temperature of 0 to
38°C.Operation at higher temperature may cause the tool's main unit to overheat. Opera-
tion at high temperature with high humidity may cause the tool to fail due to condensation.
