Instruction Manual
Electrical Cord
Rotatable Handle
Safety Trigger Switch
Model No.
TJEP No.
Power Supply
Electric Motor Type
No-Load Blade Speed
Max Cutting Capacity
Max Blade Diameter
Contents
12 Safety Instruction - General Safety
Rules
12 Work Area Safety
12 Electrical Safety
13 Personal Safety
13 Power Tool Use and Care
14 Service
14 Contents of the TJEP RC20 Rod
Cutter package
Button to rotate handle
180 degrees
Carbon Brush Access on both sides
Chip Exhaust Area
able Cutting Chip Catch Bag)
Cutting Head
Electric Motor
Removable Side Handle - Three
positions
TJEP RC20 Rod Cutter
102940
240V- 50 Hz, 4.6 Amp, Single phase
1100 Watt Double Insulated
2,000 RPM
20 mm
110 mm
14 Functions and Applications
15 Specification
15 Operation
15 Operation Instructions
16 Check The State of Your Work Site.
16 Remove Hazardous Substances.
16 Maintenance of the Main Unit
16 TJEP RC20 Blade
16 General Operating Cautions
English
(shown without attach-
Blade Spindle Locking
Button
Adjustable Stop
for Cutting
Cutting Slot
Opening and
blade
Flush Cutting Bottom Plate
11
