2 Symbols
Warning of general danger
Risk of electric shock
Read the Operating Instructions/Notes!
Wear ear protection.
Wear a dust mask.
Wear protective goggles.
Do not throw in the household waste.
Fastening / Drilling mode
Impact drilling mode
3

Machine features

[1-1] Bit store
[1-2] LED light switch
[1-3] LED lamp
[1-4] Speed set button
[1-5] Switch for selecting drilling/fastening or
impact drilling mode (only PD 20/4 E)
[1-6] Gear switch
[1-7] On/Off switch
[1-8] Right/left switch
[1-9] Mains power cable
[1-10] Belt clip
[1-11] Additional handle
The specified illustrations appear at the beginning
of the Operating Instructions.
4 Intended use
The machine
DR 18/4 E
– was designed for drilling into wood, metal, ce-
ramic and plastic.
PD 20/4 E
12
– was designed for impact drilling into tiles, con-
crete and masonry as well as
– drilling into wood, metal, ceramic and plastic.
Machines with forward/reverse setting are also
suitable for fastening screws and tapping threads.
The user is liable for improper or non-in-
tended use.
5 Safety instructions
5.1

General safety instructions

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future ref-
erence.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or bat-
tery-operated (cordless) power tool.
5.2 Machine-related safety instructions
– Wear ear protectors when impact drilling. Expo-
sure to noise can cause hearing loss.
– Use auxiliary handle(s), if supplied with the
tool. Loss of control can cause personal injury.
– Hold power tool by insulated gripping surface,
when performing an operation where the cut-
ting accessory or fastener may contact hidden
wiring or its own cord. Cutting accessory or fas-
teners contacting a "live" wire may make exposed
metal parts of the power tool "live" and could give
the operator an electric shock.
– The machine must never be operated when wet
or located in a damp environment. Connect de-
vices that you intend to use outdoors via an earth
leakage circuit breaker (FI) with a maximum re-
lease current of 30mA. Always use a cable ap-
proved for outdoor use.
– Wear suitable protection: such as ear protec-
tion, safety goggles, a dust mask for work which
generates dust, and protective gloves when
working with raw materials and when changing
tools.
CAUTION! Rebound!
Rotation: Switch off device immediately!
– Do not lock the on/off switch permanently!
– Secure the workpiece using clamping devices.
– Check the plug and the cable regularly and
should either become damaged, in order to avoid
