video mode

Locate the video switch
desired position. The following modes are at your disposal.
- Motion detection mode
- Playback mode
- Recording mode (receiving/recording/photo taking)
antenna
The preinstalled antenna (8) can be hidden for protection
purpose. For better reception during use turn the antenna fully
up. After use turn in down again.
The antenna can be replaced by the antenna switch cable (18):
1. Carefully pull the antenna out of the antenna socket. Hold
the antenna as close as possible to the socket.
2. Insert the SMB connector of the switch cable. Make sure
it locks in place.
3. You may now connect an external antenna featuring a
male SMA connector to the female SMA connector.
4. Always put the protective cap on the SMA connector on
the switch cable when no external antenna is connected.
(13). Slide the switch to the
access storage on computer
1. Turn the monitor off.
2. Connect the monitor to a free USB port on your computer
via the provided USB cable. Connect the Mini B plug of
the cable to the Mini USB socket (17) and the A plug to the
USB port on your computer.
3. Turn the monitor on. Your computer will install the
necessary drivers automatically.
4. On completion of driver installation open the removable
disk image. Open the "DCIM" directory. Videos are located
in the "RECORD" directory and photos in the "PHOTO"
directory.
For videos, subdirectories are allocated according to
recording date. Open them to gain access to videos.
Photo file names contain recording date and time.
