16 Secure the canopy by aligning the
EN
Velcro® strips on the console and
canopy.
17 Remove the canopy: Press the top gray
button on the Accessory Mounting
Bracket to release the canopy peg and
unfasten snaps and Velcro® at the top of
the canopy.
ADJUSTING SAFETY HARNESS
18 From the back of the seat, undo the
fastening strip and open the pocket to
locate the plastic square stopper. Turn
stopper and pass through the openings
in the PE board and seat fabric.
19 Reinsert stopper at seat opening closest
to child's shoulders. Pass back through
seat fabric and PE board. Tug on strap to
ensure stopper is locked. Repeat on both
sides.
WARNING: Avoid serious injury from
falling or sliding out. Always properly
adjust and fasten safety harness.
WARNING: Always use the crotch strap
in combination with the shoulder straps
and waist belt.
20 Slide the harness pads up to access
plastic guide on strap.
21 Hold the plastic guide and pull strap to
tighten or loosen.
USING SAFETY HARNESS
22 Insert side strap buckle into harness
buckle on both sides.
23 Insert connected harness and side strap
buckles into the sides of the crotch
buckle.
24 Press button on crotch buckle to release.
RECLINE THE SEAT
25 Pinch the clamp behind the seat, and
slide it down to desired recline.
26 Pull seat down on both sides to match
the clamp position. Reverse steps to
return to the upright position.
WARNING: When making adjustments
to the pushchair seat, make sure child's
head, arms, and legs are clear of moving
seat parts and pushchair frame.
Do not recline the seat while jogging.
WEATHER COVER
If desired, pull the weather cover down
and over the seat back mesh. Secure
firmly over both sides of the seat When not
in use, roll up the weather cover and fasten
it with the elastic loop and barrel provided
under the canopy fabric.
REMOVING THE SEAT PAD
27 Remove the canopy. Starting with the top
snap closest to the handle and working your
way down the entire frame, unsnap seat
from frame.
28 Unfasten the seat straps from around the
bottom/back of the frame, located behind
the Front Wheel.
29 Locate the fold strap rings connected to the
stroller frame underneath the stroller seat.
Unscrew the fold strap rings and unhook
from the fold mechanism.
30 Slide fabric out of the footwell area.
Reverse the steps to reattach the seat
pad to the frame.
BASKET REMOVAL
31 At the rear of the stroller: Unsnap the top
snaps of the basket from around the frame
tubing above the middle crossbar.
32 Unsnap the bottom snaps of the basket
from around the frame tubing below the
middle crossbar.
33 Lay the stroller on its back so the Handlebar
is resting on the floor.
34 At the front of the stroller: Unfasten the
Velcro® tab from the side plastic loops.
35 Remove the Velcro® tab from the center
plastic loop.
BASKET INSTALLATION
36 Remove seat fabric from Summit X3 by
unsnapping all snaps and sliding fabric out
of the footwell area.
37 Install front of basket by fastening the
Velcro® tab on the center and side plastic
loops.
38 Snap the top snaps of the basket around
the frame tubing above the middle crossbar
on each side. Snap the bottom snaps of the
basket around the frame tubing below the
middle crossbar on each side.
HAND BRAKE
40 If you do not have good braking action,
simply squeeze the brake handle (A)
five or six times. If the problem persists,
loosen the brake's cylinder ring (B) to
