Novy 780 Mode D'emploi Et D'installation page 16

Illumination
To activate the lights press button ⑥. The lights
will switch on at full power.
Lighting can be activated independently from the
motor.
Recirculation (option)
If recirculation has been chosen, this is to be
programmed one
activates the cleaning indication of the Monoblock
recirculation filter and changes the switch-off
delay time.
Programme (do the programming with the
motor switched off):
Simultaneously press the + and the – keys for 5
seconds until the red LED flashes 5 times. The
following functions have now been enabled:
• The run-out time has been set to 30 minutes
(instead of the default 10 minutes). Make use of
the 30 minutes run-out time.
• • The cleaning indicator for the Monoblock re-
circulation filter has been set to 200 operating
hours.
• • The red LED will light up after 200 operating
hours. This indicates that the Monoblock recir-
culation filter needs cleaning
Deactivate the programming (do the deactivate
programming with the motor turned on):
Simultaneously press + and – for 5 sec. until the
third green LED flashes 3 times. Attention! This
is not recommended for a cooker hood with
recirculation.
Maintenance
Grease filter
The cooker hood contains 2, 3 or 4 metal grease
filters, dependent on the type number.
Grease filter indication:
--------------------------------------------------------
Indication: 4 flashing LEDs
--------------------------------------------------------
After 20 cooking hours, the 4 LEDs will start to
blink during 5 minutes, this indicates that the
grease filter has to be cleaned. When replacing
the cleaned filter, you have to reset the hood by
pushing the – button during 5 seconds. If you
don't reset, the LED lights will continu blinking.
We advise you to clean your filter twice a month
for an optimal operation.
780-C Gebruik NL-FR-DE-EN.indd 16
time. This programming
Access to the filter:
Open the rotating valve (A). Protect the hob. You
can take the grease filter (B) from the hood by
pulling the handle on the filter. The filter will come
down.
Cleaning the filter:
• in the dishwasher
• manually: in a hot solution of water and a liquid
detergent. Rince and allow to dry completely
Important! The previous instructions need to
be followed. If not an increased fire hazard may
occur.
Important! The previous instructions need to
be followed. If not an increased fire hazard may
occur.
EN 16
15/09/15 17:34
