Latchways PRD R20 Mode D'emploi page 12

EN EN
Using the Latchways PRD
Fitting and adjusting the harness (continued)
Figure 13
Figure 14
Figure 15
Figure 16
12
Note: If adjustment of the shoulder straps is required, remove
the harness and undo the zips on either side of the backpack
(Figure 13). Adjust the shoulder straps by sliding the shoulder strap
adjustment buckles and cross strap buckle (where the shoulder
straps cross). Check adjustment by continuing to try on the harness
until the chest strap and connection point are correctly positioned.
• Connect the leg buckles
by pulling the straps through the buckles to achieve a snug fit
(Figure 14).
• Where included (RH3 harness only), connect the waist belt
buckle at the front, and adjust the strap by pulling the strap
through the buckle to achieve a snug fit (Figure 15).
• Use the plastic sliders to secure any free strap. (Figure 16).
(B) (Figure 11). Adjust the leg strap
