The tool is robust and requires very little daily maintenance.
Compliance with the following points should help to maintain the optimum performance of the tool.
4.1) Accurate cleaning
Dust, sand and dirt are a danger for any hydraulic device.
Avoid putting the head on muddy or dusty ground. Any dirt particles may score the ram and cre-
ate oil leaks.
Every day, after use, the head must be cleaned with a clean cloth, taking care to remove any residual
particles, especially around the moving parts.
4.2) Replacement of the automatic coupler
To replace the automatic coupler proceed as follows:
– Remove the old coupler.
– Carefully clean the thread of the cup (01) to remove the old sealant.
– Apply tefl on tape to the thread.
– Fit the new automatic coupler (14) and tighten to 30 Nm (22 lbf ft).
4.3) Storage (Ref. to Fig. 11)
When not in use, the head should be stored and transported in the steel case, to prevent damage.
Steel case: VAL RHTEP: size 230x115xh52 mm (9x4.5x2 in.); weight 0,9 kg. (2 lbs).
The case will also store the "GO/NO GO" gauge CAL ... and the two plungers OG ...
The oil pressure in the head must always be completely released before disconnecting the head
from the hose.
Code N° Item
6840070 01 CUP
02
6360268 O-RING
6232001 03 LABEL TG.0350

04 CYLINDER

05 RAM RETURNSPRING

06 WASHER
07
6900670 SCREW

08 RAM
The items marked () are those Cembre recommend replacing if the tool is disassembled.
These items are supplied on request in the "Spare Parts Package"
The guarantee is void if parts used are not Cembre original spares.

Code N° in the various versions of the head
item
RHTEP-S RHTEPD-S
04 6120175 6120175 6120181
05 6520341 6520341 6520341
06 6641042 6641046 6641042
08 6620226 6620226 6620226
09 6232076 6232076 6232246
4. WARNING
5. PART LIST (Ref. to Fig. 10)
DESCRIPTION Qty
1
1
1
1
1
1
2
1
RHTEPF-S RHTEPE-S12 RHTEPE-S16
6120171
6520430
6641046
6620225
6232247
Code N° Item

09
6650118 10
6340060 11
12
6040240
13
6360320
6060120 14
6800186 15

6000017
When ordering spare parts always specify
the following:
6120171
- code number of item
6520430
- name of item
6641038
- type of tool
6620225
- tool serial number
6232337
DESCRIPTION
METAL LABEL
ø 2,5x3,5 RIVET
M 6x6 GRUB SCREW
BACK-UP RING
O-RING
Q14-MS COUPLER
PROTECTION CAP
SPARE PARTS PACKAGE
