8 en
Installing BL 200 Strobes
1. Remove the electrical unit from the base lock by
turning it to the left.
2. Drill the prepared fastening holes in the base (see figure 1, page 4).
3. Twist the cable entry connectors into the base, feed the cables through
and tighten the base (see figure 2, page 4).
4. Connect the wires to the terminal block (see figure 3, page 4).
5. Refasten the electrical unit to the base. To do this, turn the electrical
unit to the right until it clicks into place.

Technical Specifications

Electrical
Operating voltage
Current consumption
– at 12 V DC
– at 24 V DC
Switch-on current
Flash frequency
Flash energy
– at 12 V DC
– at 24 V DC
Service life
(in number of flashes)
Mechanical
Material
Color
– Base
– Lens
Dimensions (H x ∅)
Weight
Environmental Conditions
Permissible operating temperature
Certification according to
Environment type
Protection category as per IEC 60529
F.01U.013.098 | A3 | 2007.11
10-30 V DC
100 mA
170 mA
<1 A
1 Hz (±10 %)
0.7 J
1.3 J
Min. 5 million
Max. 50 million
Polycarbonate (PC)
Red, RAL 3001
Red, white, yellow, green
112.5 mm x 93 mm
320 g
-20 °C to 55 °C
DIN EN 54-3
Type A
IP 65
BL 200
Bosch Security Sytems
