Place the jigsaw with attached adaptation table
on the adapter [11-1] on the circle cutter.

Insert the centring mandrel [11-2] in the hole
[11-4] on the circle cutter aligned with the saw
blade.

Clamp the measuring tape to the circle cutter
using the rotary knob [11-5].
Recommended when using the circle cutter:

Cut in an anticlockwise direction.

Work at a slow rate of advance.

Set the pendulum stroke [1-11] to 0 - 1.

Set the stroke rate [1-5] to 1 - 5.
 Store the centring mandrel in the depot [11-3].
Systainer
A
B 12.1
Systainer
Many Festool products are shipped in a unique sys-
tem container, called "Systainer". This provides
protection and storage for the tool and accessories.
The Systainers are stackable and can be inter-
locked together. They also can be interlocked atop
Festool CT dust extractors.
To open the Systainer
Turn the T-loc [12-1] to this position.
To lock the Systainer
Turn the T-loc [12-1] to this position.
To connect two Systainers
Place one Systainer on the top of the other (Fig. [12
A]).
Turn the T-loc [12-1] to one of this posi-
12
tions (Fig. [12 B]).
The Systainers are connected and locked.
 A new generation Systainer is connectable on
top of a previous generation Systainer by the
four latches of the previous Systainer.
