5.2 Connecting and selecting
GB
a storage medium
1) To replay audio files on an SD/ MMC card, in-
sert this card into the slot SD MMC CARD (9).
The bevelled corner of the card must show to
the right and to the unit.
2) To replay audio files on a USB stick, connect
this USB stick to the USB port (1).
3) After switching-on, the unit always selects the
USB connection. USB flashes in the display (2).
If no storage medium has been connected, NO
USB is displayed.
With the USB memory connected, the num-
ber of titles (large number) and the number of
folders (small, upper number) are displayed
after reading in. In addition, STOP is displayed,
i. e. the unit is set to stop.
4) To switch between memory card and USB
memory, press the button FUNC (5). With this
button also the input AUX INPUT (17) for MP3
recordings is selected (
display (shortly) shows the selection:
USB = USB connection
CARD = SD / MMC card
AUX = input AUX INPUT
5.3 Playing the titles
1) With the button
replay of the first title. To select another title,
see chapter 5.4.
While playing, the display (2) shows the title
number and the time already played of the title
(min. : sec.). The small, upper number shows
the number of the folder containing the title. Ti-
tles without folder are in the ROOT directory
marked with No. 1.
2) With the buttons VOL (12) adjust the output
level (volume) so that the unit connected to the
jacks OUTPUT (16) is adjusted to an optimum
level (indication: VOL 00 ... VOL 30). If the level
is too high, the signal will be distorted, if the
level is too low, interfering noise may become
audible.
3) To interrupt the replay, set the unit to pause with
the button
tion flashes. To continue the replay, press the
button [PLAY/ PAUSE] again.
4) For displaying information about the title in-
stead of the time indication, keep the button
FIND (18) on the remote control pressed for
1 second while playing a title. The display suc-
*Lettering on the remote control
12
chapter 5.11). The
(7) [PLAY/ PAUSE*] start the
[PLAY/ PAUSE]. The time indica-
cessively shows the following information (if
available):
FILE*
TITLE
ARTIST
ALBUM
* Only shown when starting the replay.
Note: In the pause mode the display always shows
the time already played in a flashing way.
With the button FIND it is possible to go back to
the time indication in the same way.
5) To stop the replay, press the button
[STOP*]. The player is set to stop and the dis-
play shows STOP.

5.4 Title selection

5.4.1 Direct selection of the title number
The title can directly be selected by entering its
number with the numerical keys (14). To start the
title, press the button
amples:
Title No. Buttons
4 4, [PLAY/ PAUSE]
27 2, 7,
135 1, 3, 5,
Note: The titles are consecutively numbered by the unit
as follows:
1. all titles without folder in the ROOT directory.
2. all titles in folders in the ROOT directory
3. all titles in subfolders etc.
The folders are not numbered in alphabetic order but the
number of the folder can easily be found with the folder
search function ( chapter 5.4.4). The title numbers
are also displayed during alphabetic search of titles
( chapter 5.4.3).

5.4.2 Advancing or reversing titles

To advance or reverse one or several titles, shortly
press the button
CUE*](8).
Button [UP/ CUE]: Advance to the next title
Button [DOWN / REV]: Reverse to the begin-
ning of the present title. Each time the button
[DOWN / REV] is pressed, the unit will always go
back one more title.
Note: Press the buttons
CUE] only shortly, otherwise this will result in fast for-
ward or reverse.
(7) [PLAY/ PAUSE*]. Ex-
[DOWN / REV*] or
[DOWN / REV] and
(6)
[UP/
[UP/
