2 Important Notes
The unit corresponds to all relevant directives of
the EU and is therefore marked with
G
The unit is suitable for indoor use only. Protect
it against dripping water and splash water, high
air humidity, and heat (admissible ambient tem-
perature range 0 – 40 °C).
G
For cleaning only use a dry, soft cloth, never
use chemicals or water.
G
No guarantee claims for the unit and no liability
for any resulting personal damage or material
damage will be accepted if the unit is used for
other purposes than originally intended, if it is
not correctly connected or operated, or not re-
paired in an expert way. Likewise, no liability for
data loss caused by operating error or by a de-
fect or its consequential damage can be ac-
cepted.
If the unit is to be put out of operation de-
finitively, take it to a local recycling plant
for a disposal which is not harmful to the
environment.

3 Applications

The MP3 recorder DPR-10 allows to replay MP3
and WMA files (data rate 256 kb / s max.) of USB
sticks and SD / MMC cards (up to 4 GB, FAT 32).
For recordings in the MP3 format an audio unit
(radio, CD player, tape deck etc.) may be con-
nected. In addition, it is possible to copy titles from
an SD / MMC card to a USB stick and vice versa.
The DPR-10 can be operated as a separate
unit but due to its compact size it can also be built
into another unit (e. g. into an active speaker sys-
tem). During installation it has to be ensured that
the MP3 recorder will be sufficiently ventilated.
Otherwise it may be damaged by overheating.
4 Connections
Prior to the connection or changing the connec-
. tions switch off the DPR-10 and the units to be
connected.
1) Connect the jacks OUTPUT (16) via a cable
with phono connectors to a line input e. g. at a
mixer or amplifier (L = left channel, R = right
channel).
2) For recordings on an SD / MMC card or a USB
stick, connect an audio unit with line output
(e. g. radio, CD player, tape deck) to the jacks
AUX INPUT (17).
3) For power supply a regulated 12 V power
supply unit with a permanent rating of 400 mA
and a low voltage plug of the dimensions
5.5/2.1 mm (outside/inside diameter) is re-
quired (e. g. PS-1250DC from MONACOR).
Connect the power supply unit to the jack
12 V
positive pole must be at the centre contact!
5 Operation
Switch on the unit with the POWER switch (11).
The display (2) shows HELLO as a welcome. If the
USB connection
age medium, NO USB is shown after a short time.
5.1 Remote control
1) To insert the batteries (2 × 1.5 V, size AAA),
press the arrow of the cover on the rear side of
the remote control and slide the cover down-
wards. Insert the batteries as indicated in the
battery compartment. Close the compartment
with the cover.
Remove the batteries if the remote control
will not be used for a longer period of time so
that it will not be damaged in case the batteries
should leak.
2) Always hold the remote control in the direction
of the sensor IR (10) when pressing a button.
There must be no obstacles between the re-
mote control and the sensor.
3) If the range of the remote control decreases,
the batteries are almost exhausted and have to
be replaced.
(15). Observe the correct polarity: The
(1) is not connected to a stor-
Do not put exhausted batteries into the
household rubbish. Always take them to
a special waste disposal (e. g. collecting
container at your retailer).
