The instructions in this manual are task-oriented for easy reference. You can go directly to a particular section and
quickly find the answers. Appendix A and B list MASTERFLEX
system.
These Cartridge Pumps are designed to provide up to 8 simultaneously driven pump channels and incorporate the fol-
lowing features.
Simultaneous dispensing into 8 separate containers with one set-up and pump cycle.
The four-roller design provides reduced pulsation.

(1) Application Data

The Cartridge Pump System is designed for multi-channel use where close occlusion control of a variety of different flows
is required. Tubing found in Table 3 may be used to deliver from .074 to 1700 mL/min.

(2) General Description

Each Pump Head System is composed of a heavy duty Pump Head and two sizes of snap-in tubing Cartridges, each with
individually adjustable occlusion settings. The occlusion "wedge" design provides accurate and more balanced flow con-
trol.
The Pump Heads contain either three or four rollers. Both models can operate with a variety of tubing and with either the
small or the large Cartridges.
The Pump Head quickly mounts to most existing MASTERFLEX

INTRODUCTION

Pump Heads

MODEL
Model 07519-05
Model 07519-06
Cartridges
MODEL
Model 07519-70
Model 07519-80
® ®
L/S pump drive types which can be used with this
TYPE
3-Roller, 4 or 8 Channel
4-Roller, 4 or 8 Channel
TYPE
Large
Small
® ®
L/S Pump Drive types (see Appendix A and B).
