Holding register Name
(Protocol)
40141 Acknowledge
(140)
40142 Alarm history index
(141)
40143 Alarm history error
(142) code
State float swiches
40198
(197)
40204 Set points water le-
(203) vel 1
40205 Set points water le-
(204) vel 2
40206 Set points water le-
(205) vel 3
40212 Set points water le-
(211) vel 1
40213 Set points water le-
(212) vel 2
40214 Set points water le-
(213) vel 3
40220 Dry run level
(219)
40222 High water level
(221)
54
Annexe
Data type Scale & unit
BOOL
UINT16
UINT16 0.1
BITMAP
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
UNIT16 1 cm
Elements Access
13: Frost
14: Battery Low
15: High water
16: Priority off
17: Redundancy
18: Plausibility
19: Slave com-
munication
20: Net supply
21: Leakage
W
RW
R
0: DR R
1: Ps off
2: P1 on
3: P2 on
4: HW
RW
RW
RW
RW
RW
RW
RW
RW
Added
31.000
31.000
31.000
31.102
31.102
31.102
31.102
31.102
31.102
31.102
31.102
31.102
