13. Schémas d'installation
13.1.1 Kit 1 ligne
Sonnette
porte
Doorbell Button
Switch
Kit 2 lignes
13.1.2
Sonnette
porte
Doorbell Button
Switch
Sonnette
porte
Doorbell Button
Switch
-13-
Vac
AC~
PG N L L
PC6
BUS(IM) BUS(DS)
BUS (M)
BUS (DS)
Moniteur
Platine
Vac
AC~
PG N L L
PC6
BUS(IM) BUS(DS)
BUS (M)
BUS (DS)
Moniteur
Platine
L1 L2 PL S+ S-
-
+
L1 L2 PL S+ S-
-
+
