Getting started

Inserting the batteries in the thermometer
Remove the protective film from the display.
y
Open the battery compartment (Fig.1-B) on the back of the thermometer
y
and insert two new batteries 1.5 V AAA. Make sure the polarities are correct.
Close the battery compartment. The device will alert you with a beep, all LCD
segments will be displayed and the backlight will turn on for a short moment.
The device is ready for use.
The current temperature, the cooking chamber symbol (Fig.5-H) and the
y
battery symbol (Fig.5-B) appear on the display.
Connect the probes
y Pull off the rubber protection cover (Fig.1-C) carefully from the opening of the
first probe on the left side of the thermometer. Plug the probe cable connector
(Fig.3-K) into the jack (Fig.3-J).
y Repeat the process for the second probe.
The display now alternately shows the current temperatures measured by the
y
cooking chamber sensor, the insertion probe 1 and 2 (Fig.5-G).
You can also operate the device with only one or without probe.
y
Mounting the thermometer on the barbecue lid (Fig.4)
Make sure your barbecue has a double-walled lid, otherwise heat can
y
damage the thermometer.
y The pre-drilled hole must have a diameter of 9 to 14 mm and a
depth of 6 to 27 mm.
Put the heat insulation plate (Fig.2-E) on the hole. The flat, longer side facing
y
up. Now put the shaft through the hole and fix the thermometer on the back of
the lid with the washer (Fig.2-F) and the screw nut (Fig.2-G).
Switch the devices off and on
Press and hold the control button (Fig.1-A) for three seconds.
y
y The device is switched off.
Press and hold the control button to turn the device back on.
y
IMPORTANT: To increase the life of the batteries, switch off the device after each use!
16
Download the app
Download the free HyperBBQ app from the "Apple App Store" or "Google Play
y
Store".
y Make sure your mobile phone meets the following requirements:
Compatible with iPhone 4S (or later), iPod touch 5th generation (or later),
iPad 3rd generation (or later), iPad mini
Android™ Smartphone 4.3 (or later).
Connect to the mobile device
y Start the app and follow the instructions on the screen to establish connection.
Hold down the control button (Fig.1-A) for 3 seconds and switch on the
y
thermometer.
y Briefly press the control button to pair.
You do not have to repeat the pairing process for other applications unless you
y
switch to another mobile device.
Google Play and the Google Play logo are trademarks of Google LLC. Android is a trademark of Google LLC.
Apple, Apple Watch, iPad, iPod, iPod touch, and iPhone, are trademarks of Apple Inc., registered in the U.S. and other coun-
tries. App Store is a service mark of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered
trademark of Cisco in the U.S. and other countries and is used under license.
HyperBBQ App (Fig.6)
The app 's appearance can differ between iOS and Android™ and may change after an
update. Please always follow the current instructions in the app.
Fig.6-A - Options
Fig.6-B - Connection status
Fig.6-C - Duration
Fig.6-D - Timer
Fig.6-E - Photo function
Fig.6-F - Current temperature probe 1
Fig.6-G - Probe 1 and 2 with selected
colour marking
Fig.6-H - Selected dish with
target temperature
Fig.6-J - Current temperature
cooking chamber
Fig.6-K - Cooking chamber sensor with
selected colour marking
Fig.6-L - Selected dish with lower/upper
temperature limit
Fig.6-M - Battery symbol for
the thermometer
Fig.6-N - Device settings
