en
PID PID description
Total Run Time with EI-AECD
AECD8_
#8 Timer 1 Active, #2 Timer
TIME1, TIME 2
Active
Total Run Time with EI-AECD
AECD9_
#9 Timer 1 Active, #2 Timer
TIME1, TIME 2
Active
ALCOHOL Alcohol Fuel Percent
BARO PRS Barometric Pressure
Hybrid Battery Pack Remain-
BAT_PWR
ing Life
BP_A_ACT, B_ Boost Pressure Sensor A, Sen-
ACT sor B
BP_A_CMD, Commanded Boost Pressure
B_CMD A, Pressure B
BP_A_STAT, B_ Boost Pressure A Control Sta-
STAT tus, B Control Status
Charge Air Cooler Temper-
CACT 11, 12 ature Bank 1 Sensor 1 sup-
ported, Sensor 2 supported
Charge Air Cooler Temper-
CACT 21,22 ature Bank 2 Sensor 1 sup-
ported, Sensor 2 supported
CALC LOAD Calculated Engine Load
CAT TEMP11, Cataltic Converter Temp
TEMP12 Bank1, Temp Bank 3
CAT TEMP21, Cataltic Converter Temp
TEMP22 Bank2, Temp Bank 4
CLR DIST Distance since erase
CLR TIME Minutes Run since Erase
CLR TRPS Warmups Since Erase
Commanded Equivalence
CMD EQ RAT
Ratio
COOLANT Engine Coolant Temp
DPF_REG_ Average Distance Between
AVGD DPF Regen
DPF_REG_ Average Time Between DPF
AVGT Regen
DPF_REG_ Diesel Particulate Filter (DPF)
STAT Regen Status
Diesel Particulate Filter (DPF)
DPF_REG_TYP
Regen Type
DPF_REGEN_ Normalized Trigger for DPF
PCT Regen
Bosch Automotive Service Solutions
| OBD 1100 | Operating instructions | 11
PID
DPF1_DP,
DPF2_DP
DPF1_INP,
DPF2_INP
DPF1_INT,
DPF2_INT
DPF1_OUTP,
DPF2_OUTP
DPF1_OUTT,
DPF2_OUTT
ECT 1, 2
EGR CMD
EGR ERR
EGR_A_ACT,
B_ACT
EGR_A_CMD,
B_CMD
EGR_A_ERR,
B_ERR
EGRT 11, 21
EGRT 12, 22
EGT 11, 21
EGT 12, 22
EGT 13, 23
EGT 14, 24
EMIS_SUP
ENG RUN
PID description
Diesel Particulate Filter (DPF)
Bank 1 Delta Pressure Bank 2
Delta Pressure
Diesel Particulate Filter (DPF)
Bank 1 Inlet Pressure, Bank 2
Inlet Pressure
DPF Bank 1 Inlet Temperature
Sensor, Bank 2 Inlet Tempera-
ture Sensor
Diesel Particulate Filter (DPF)
Bank 1 Outlet Pressure,
Bank 2 Outlet Pressure
DPF Bank 1 Outlet Temper-
ature Sensor, Bank 2 Outlet
Temperature Sensor
Engine Coolant Temperature
1, Temperature 2
Comanded EGR
Exhaust Gas Recirculation
Error
Actual EGR A Duty Cycle / Posi-
tion, B Duty Cycle / Position
Commanded EGR A Duty
Cycle / Position, B Duty Cycle /
Position
EGR A Error, B Error
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 1,
Bank 2 Sensor 1
Exhaust Gas Recirculation
Temperature Bank 1 Sensor 2,
Bank 2 Sensor 2
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 1, Bank
2 Sensor 1
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 2, Bank
2 Sensor 2
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 3, Bank
2 Sensor 3
Exhaust Gas Temperature
(EGT) Bank 1 Sensor 4, Bank
2 Sensor 4
Emission requirements to
which vehicle is designed
Time Since Engine Start
