Faber Levante I Instructions D'installation page 15

Installation Instruction for mounting on the Wall
A1
A2
A
24" - - > A= 21
30" - - > A= 27
36" - - > A= 33
Mark the wall where indicated, 4
horizontal line and at A distance on the left and
right of vertical line.
=
Min. 24"
A3
"
3/8
"
3/8
"
3/8
" above the Mark the wall where indicated, 1" above the hori-
15/16
zontal line and at A distance on the left and right
of vertical line.
=
Draw a vertical line on the supporting wall as
high as practical, at the center of the area in
which the hood will be installed.
Draw a horizontal line at where the bottom
edge of the hood will be located as indicated
cooking surface
A
24" - - > A= 21 "
3/8
30" - - > A= 27 "
3/8
36" - - > A= 33 "
3/8
15
