Hayward AquaVac MakoShark 2 DC Guide De L'utilisateur page 28

57 RCX1601
AI RCX1814D
58 RCX1606
59 RCX1607A
60 RCX1607
61 RCX1605
62 RCX1114A
AJ RCX1608
AK RCX1606A
AM RCX1814C
AN RCX1113
63 RCX1800F
AO RCX1808
64 RCX1104DC
65 RCX1102A
66 RCX4148P82
67 RCX4209
PLATE - WHEEL OUTSIDE
RING SNAP 1/2''
LOCK - WHEEL DRIVE W/ STUD
PISTON - WHEEL LOCK SS
SPRING - WHEEL LOCK SS
WASHER - WHEEL PLASTIC
BUTTON - WHEEL
CLIP "E" 1/4'' SS
NUT LOCK HEX 10-24 SS LOW PROFILE
WASHER FLAT 7/16''
KEY 1/8'' SS - DRIVE WHEEL
GEAR BOX ASSEMBLY - FLEX
BOLT HEX HD 1/4 - 20 X 1 1/4'' SS
IMPELLER - 3 BLADES
COLLAR - IMPELLER FLEX DRIVE
HOUSING - PUMP PLASTIC
PAD - MOTOR RUBBER NS
12
2 1 1
2 1 1
2 1 1
4 2 2
4 2 2
8 4 4
8 4 4
8 4 4
4 2 2
2 1 1
2 1 1
1
5
1
1
1
1
