Undo the end cap nut (1) on the end cap (2) and take the end cap (2),
o-ring (14) and the viewing glass (3) off the UV-C.
5.
Take the quartz glass tube (13) out of the UV-C.
6.
Clean the quartz glass tube (13) with a soft sponge, avoiding scratching
it, and dry it with a clean, soft cloth.
7.
Clean the UV-C on the inside with a soft sponge and dry with a soft
cloth.
8.
If the quartz glass tube (13) is damaged or cracked, it must be replaced.
9.
Place the quartz glass tube (13) back in the UV-C; ensure that the
quartz glass seal (4) sits properly on the plastic part of the quartz glass
tube (13). (Make sure the cap (25) sits on the quartz glass tube if you
have the 75W version).
10. Replace the viewing glass (3) with the seal (4) in the UV-C.
11. Make sure that the o-ring (14) sits properly in the groove on the viewing
glass (3).
12. Replace the end cap (2) and do up the end cap nut (1) securely.
13. Make sure that the o-ring (14) sits properly in the groove on the plastic
part of the quartz glass tube (13).
14. Place the UV-C lamp (16) and the lamp fitting cap (17) back in the UV-C.
Make sure that the pin of the safety switch in the plastic part of the
quartz glass tube (13) sits in the hole on the safety switch in the lamp
fitting cap (17). Check the markings on the plastic part of the quartz
glass tube (13) ad the lamp fitting cap (17).
15. Do up the end cap nut (1) securely.
16. Before the VarioClean Pro is switched on, all nuts and connectors must
be checked to ensure that they are secure and watertight.
17. The VarioClean Pro can be switched on by first turning on the pump so
that water flows through the UV-C, and then switching on the VarioClean
Pro itself.
18. Check for leaks. If there are any leaks, the UV-C and pump must be
switched off and the leak fixed before the UV-C is switched on again.
Description of parts: (figure 7)
No. Description
1
End cap nut
2
End cap
3
Viewing glass
4
Seal
5
Flat seal large
6
Threaded flange
7
Coupling nut
8
Cap
9
Screw
10
Clamp large
11
Foot with ballast
12
Entry and exit point
13
Quartz glass tube
14
O-ring
Parts can be ordered from your dealer, please indicate drawing number,
description and the type of UV-C when ordering.
English
www.auga.nl
No. Description
15
Lamp holder
16
UV-C lamp
17
Lamp fitting cap
18
Hose fitting
19
Flat seal small
20
Transparent connector large
21
Transparent connector small
22
O-ring small
23
Foot (only with 75W)
24
Clamp small (only with 75W)
25
Cap
26
Clamp nut
27
Stainless steel tube
