When choosing the material for parts that come into contact with water after the VIVREAU filter sys-
•
tem, it is important to remember that, due to the process, decarbonised water contains free carbon
dioxide. For this reason, only materials that are compatible with free carbon dioxide must be used.
Note: The water is not decarbonised when using PURITY C AC filter cartridges.
All parts must be installed in accordance with the country-specific guidelines on the installation of
•
drinking water facilities.
4 Installation
Caution: Prior to installation, read the technical data (Chapter 9) and the operating and safety
!
information (Chapter 3). After storage and transport below 0 °C (32 °F), the product must be stored
in the open original packaging for at least 24 hours before it is commissioned at the stated ambient
temperatures (Chapter 9) for operation.
4.1 Assembling the filter head, water connection
Close the water intake and switch off the power supply to the end device.
•
A
Fit the wall mounting bracket
•
Caution: When fitting the bracket, note the installation dimensions, bending radii of
B
!
the hoses and dimensions of the accessories (e.g. VIVREAU FlowMeter). When using
the wall mount, install vertically only! The PURITY C1100 cannot be installed using the
C
wall mounting bracket.
Fit the hoses to the water inlet "IN"
•
D
Caution: The max. tightening torque at the connections must not exceed 14 Nm!
!
When using PURITY C 0 – 70% filter heads, check bypass setting
•
factory) and if necessary adjust this setting to the local carbonate hardness ( c hapter 4.2).
Lock the filter head
•
4.2 Bypass setting for and capacity of PURITY C 0 – 70% filter heads
Determine the carbonate hardness (for PURITY C filter cartridges) by performing the
•
VIVREAU carbonate hardness test. Alternatively, your local water supplier will be able to
provide information on the local water hardness.
Determine the bypass setting and capacity in line with the application and the carbonate
•
h ardness identified using the bypass and capacity table (pages 2–5).
Then turn the bypass setting
•
To ensure precise and continuous control of the degree of filter cartridge exhaustion, it is
•
r ecommended to install the VIVREAU FlowMeter 10 – 100 A.
•
Note: With PURITY C1000 AC and PURITY C Finest filter cartridges, all of the intake water is
filtered. The filter cartridge can be used with filter heads that have a variable or fixed bypass. The
bypass that may be set in the filter head is not taken into account.
4.3 Inserting the filter cartridge
Pull the flap of the protective cap
•
E
Note the next exchange date in the date field on the filter cartridge
•
Insert the filter cartridge
•
F
Caution: The filter cartridge can only be inserted when the locking handle is open.
!
Make sure that the filter cartridge is positioned correctly.
•
Turn the locking handle
•
in the intended position.
5
and outlet "OUT"
4
in the wall m ounting bracket
1
to the identified value.
10
upwards and remove the protective cap.
7
in the filter head
6
until you feel it engage.
2
on the filter head
3
10
.
5
in a vertical position.
1
.
1
(set to 30% at the
.
6
13
EN
