Tunturi DUAL CHESTBACK-PLATE LOADED Manuel De L'utilisateur page 5

D-1
Platinum Dual ChestBack
A B
M10X130 Cylindrical head bolts
*10Pieces
D E
M10X20Cylindrical head screws M10X75Cylindrical head screws
*12Pieces
G H
M6X10Cylindrical head screws M8X16Flat round head screws
*6Pieces
J K
M8X25Flat round head screws Ø8Gasket
*12Pieces *18Pieces
5
C
Ø10 Gasket M10X9t-S1 Lock nut
*36Pieces *36Pieces
F
Cylindrical head screws M10X60
*16Pieces *6Pieces
I
Cylindrical head screws M10X65
*6Pieces *4Pieces
L
M8X75Flat round head screws
*6Pieces
