Platinum Dual ChestBack
B
A
M10X130 Cylindrical head bolts
*10Pieces
D
M10X20Cylindrical head screws
*12Pieces
i
G
M6X10Cylindrical head screws
*6Pieces
J
M8X25Flat round head screws
*12Pieces
2
B C
Ø10 Gasket M10X9t-S1 Lock nut
*36Pieces *36Pieces
E F
M10X75Cylindrical head screws Cylindrical head screws M10X60
*16Pieces *6Pieces
H I
M8X16Flat round head screws Cylindrical head screws M10X65
*6Pieces *4Pieces
K L
Ø8Gasket M8X75Flat round head screws
*18Pieces *6Pieces
