OPERATION
Before using, check the mounting and adjustment of this machine. Rotate
the Handle (#23) and check whether the four gears (#19, #30) have good,
firm contact with each other. Shafts 1, 2 and 3 should be clean and free of
metal debris. Refer to the Parts Diagram.
Forming Rolls
1. Insert the steel plate between Shaft 1 (#8) and Shaft 2 (#20).
2. Rotate the Handle (#23) to form the metal roll.
3. If the diameter of the metal roll is not correct, turn the Adjusting Bolts
(#22) clockwise to decrease the diameter, of counterclockwise to increase
the diameter of the roll.
4. To remove the finished roll, pull out Sleeve (#10) on the end of Shaft 1
(#8), nearest the Handle (#23), and swing Shaft 1 out of the Right Stand.
Then remove the steel roll from Shaft 1.
Forming Rings
The half-round slots on the right side of Shaft 2 (#20) and Shaft 3 (#7) can
beused to form rings of various dimensions.
1. Insert the steel in half-round slot of Shaft 2 (#20) or Shaft 3 (#7).
2. Rotate the Handle (#23) to form the metal ring.
WARNING: Keep the hands away from the shafts and metal plate during
operation. Do not attempt to form rolls from materials other than those
specified
- 6 -
