INSTALL THE LIFTMASTER MONITORED ENTRAPMENT PROTECTION (LMEP)
DEVICES (OPTIONAL)
Always refer to the installation instructions that are included with your LiftMaster Entrapment Protection (LMEP) devices. Without an
LMEP properly installed, the operator will only work with constant pressure to close mode of operation.
WIRE THE LIFTMASTER MONITORED ENTRAPMENT PROTECTION (LMEP)
DEVICES
1
Connect the LiftMaster Monitored Entrapment Protection
(LMEP) device to the logic board according to the models
shown below:
MONITORED PHOTOELECTRIC
SENSOR
MODELS CPS-U, CPS-UN4,
CPS-RPEN4, CPS-OPEN4
24VAC
14
24VAC
13
DATA
TIMER
DEFEAT
12
White (Blue)
COMMON
11
24VAC
POWE
MAS
24VAC
10
T MER
DEFEAT White/Black (Brown)
COMMON
LMEP
MAS
9
LMEP
EDGE 8
EDGE
OPEN
OPEN
CLOSE
7
STOP
CLOSE
6
COMMON
STOP
5
SBC
COMMON
4
3
2
SBC
1
NOTE: Only one LMEP device can be connected to the logic board. To attach additional LMEP's, the CPS3CARD option card is required.
Secondary (non-monitored) entrapment protection devices (with N.O. dry contact) will be wired to the EDGE and COMMON terminals.
MONITORED
EDGE SENSOR
24VAC
14
24VAC
13
DATA
TIMER
DEFEAT
12
COMMON
11
24VAC
POW
MAS
24VAC
10
T MER
DEFEAT
COMMON
LMEP
MAS
9
LMEP
EDGE EDGE 8
PEN
OPEN
LOS
7
STOP
CLOSE
6
COMMON
STOP
5
SBC
COMMON
4
3
2
SBC
1
21
CPS-MEI
White
Red
LiftMaster
Black
CPS-MEI
Red
CPS-EI
White
E4
White
E3
LMEP1
Black
E2
LMEP2
Black
E1
2-Wire Monitored Sensing Edge
4-Wire Sensing Edge
Entrapment Protection
