ACCESSORIES

REMOTE CONTROLS WITH SECURITY✚ 2.0
& CONNECTIVITY
LiftMaster offers a variety of SECURITY✚ 2.0
Controls for your application needs. Single to 4-Button.
Contact your authorized dealer.
811LM Universal DIP Single-Button Remote Control:
Ideal for commercial door applications requiring a large
number of remotes for a common space.
813LM Universal DIP Three-Button Remote Control:
Includes Red, Yellow and Green markings which
Indicates
Open, Close, Stop.
893MAX 3-Button Remote Control:
Can also control up to 3 MyQ
Compatible with all LiftMaster
operators manufactured since January 1993.
877LM Wireless Keypad:
Able to be programmed with temporary access
codes for visitors or delivery personnel.
STAR1000 Commercial Access Control Receiver:
Connects up to 1000 LiftMaster
Supports suspending and unsuspending remote
controls to withhold and reinstate access.
®
828LM LiftMaster Internet Gateway:
Enables owners of Commercial Door Operators to open
and close their doors and turn on/off lights in or around
their facility using a smart phone or computer from
anywhere in the world.
CONTROL STATIONS
02-101
1-Button Control Station:
Steel enclosure.
02-102
2-Button Control Station:
Steel enclosure.
02-103L
3-Button Control Station:
Steel enclosure with Maintenance Alert System.
02-110
Key Control Station:
Indoor flush mount, NEMA 1 with Stop button.
Accessories
TM
MOUNTING BRACKETS
10-12360
TM
Remote
08-9098
08-9098EZ
® enabled light devices.
® commercial door
1A4324
1A4324EZ
®
remote controls.
ENTRAPMENT PROTECTION DEVICES
CPS-U
CPS-UN4
CPS3CARD
CPS-EI
42
Heavy gauge steel bracket for vertical or horizontal
mount on either front or top of coil on a rolling door.
Has a variety of mounting hole patterns compatible
with many OEM manufacturers. For use with J, H, DJ,
and DH operators. May be welded.
Cast iron bracket to mount J, H, DH, DJ, and GH side
mount operators on end bracket of a rolling door or
grill. For vertical or horizontal mount on either front or
top of coil. Cannot be welded.
Same as 08-9098, but with adapter plate to hold
mounting bolts in place for easy mounting.
Heavy gauge steel bracket for vertical or horizontal
mount on either front or top of coil on a rolling door.
May be welded. For use with J, H, DJ, and DH
operators.
Same as 1A4324, but with adapter plate to hold
mounting bolts in place for easy mounting.
MONITORED
®
Commercial Protector System Photoelectric
Sensor:
Provides protection on doors up to 30' wide.
®
Commercial Protector System Photoelectric
Sensor:
Provides protection on doors up to 45' wide. NEMA-
4 rated.
Option Logic Board:
For use when more than one set of photoelectric
sensors are required. Also available pre-packaged with
a second set of photoelectric sensors; see CPS3 or
CPS3-N4 in Commercial Door Operator Product and
Accessories Price List for more information.
Monitored Sensing Edge Interface:
For use with the approved 4-wire edge.
