Rollo R_04 |
Store enrouleur R_04
Trägermontage
Supports de fixation Bracket mounting
Anzeichnen
Marquage Mark
1/2 Bestellbreite (1/2 Gesamtbreite)
1/2 largeur de commande (1/2 largeur totale)
1/2 ordering width (1/2 total width)
max. 40 mm
40 mm
** Hinweis Montage
Remarques concernant le montage Installation note
Montage Beton
Pose sur béton Concrete installation
Montage Hochlochziegel
Pose sur briques alvéolées Hollow brick installation
Montage Plattenbaustoff
Pose sur plaque de fixation Panel building material installation
**
2
| Roller Blind R_04
1/2 Bestellbreite - 40 mm
1/2 largeur de commande - 40 mm
1/2 ordering width - 40 mm
waagerecht ausrichten
*
alignement horizontal
*Ab Anlagenbreite mit 3500 mm links und rechts aussen 2 Clipträger verwenden.
*A partir d'une largeur de store de 3500 mm, utiliser 2 supports clips aux extrémités gauche et droite.
*From a system width of 3500 mm, use 2 clip-on brackets on the left and right outside.
Fenstermitte
Milieu fenêtre Centre of window
1/2 Bestellbreite (1/2 Gesamtbreite)
1/2 largeur de commande (1/2 largeur totale)
1/2 ordering width (1/2 total width)
1/2 Bestellbreite - 40 mm
1/2 largeur de commande - 40 mm
1/2 ordering width - 40 mm
max. 1000 mm
align horizontally
max. 40 mm
*
5,5
40
Technische Änderungen vorbehalten, Ausgabe 02.2025
Sous réserve de modifications techniques, édition 02.2025
Subject to technical changes, Edition 02.2025
