Vertiv™ Liebert® GXT5 Lithium-Ion UPS
1000-3000VA LV, 120V IN, 120V OUT
Quick Installation Guide
Model Design Configurations
GXT5LI-2000LVRT2UXL
IMPORTANT: Before installing,
connecting to supply or operating
your Liebert GXT5 Lithium-Ion
UPS, please review the Safety and
Regulatory Statements sheet. For
detailed installation, operating,
maintenance and troubleshooting
information refer to the Liebert
GXT5 Lithium-Ion User Guide for
your model available at www. V ertiv.
com.
Thank you for your recent purchase of a Vertiv UPS! We appreciate your
business and are confident that your new product will provide many years of
uninterruptible power to your connected equipment. With this purchase, you
may also want to consider Vertiv's complete line of racks, PDUs, thermal
solutions, KVM switches, and serial consoles. Vertiv also offers a broad array of
services and extended warranties. If you require any assistance or support
please don't hesitate to reach out to one of our resellers, local rep firms, or
directly to us at 1-800-222-5877 menu option 3, or email at microups.
warranty@vertiv.com. We stand ready to support you. We sincerely hope that
you'll continue to select Vertiv for all of your future infrastructure needs!
The Vertiv Team
GXT5LI-1000/1500LVRT2UXL
# Description
1 USB port
External Battery Cabinet (EBC)
2
CAN ports
3 RS-232 port (used for CLI)
Dry contact communication
4
terminal block
Remote Emergency Power Off
5
(REPO)
6 EBC terminal
7 Input power plug and cable
GXT5LI-3000LVRT2UXL
Non programmable output
8
receptacles
Programmable output
9
receptacles
10 Input circuit breaker
11 Liebert® IntelliSlot Port
12 Output power plug and cable
13 Output circuit breakers
31014371/SL 70870_REVA_12_21
