BIG ASS FANS Mammoth Manuel D'installation

LIGHT OR LOWER COVER INSTALLATION
WARNING: Power must be disconnected before installation and servicing,
cleaning, and other user maintenance. Failure to disconnect power creates risk
of fire, electric shock, and serious bodily injury.
CAUTION: The Big Ass Fans product warranty will not cover equipment damage
or failure that is caused by improper installation or use.
Remove old light or lower cover from bottom of fan by twisting counterclockwise.
Disconnect light wiring harness from "LED" receptacle on bottom of fan.
If installing a new light, plug light wiring harness into "LED" receptacle on bottom of fan
(Fig. 1a). Align screws on top of light or lower cover with slots on bottom of fan and twist
light (Fig. 1a) or lower cover (Fig. 1b) clockwise to lock.
Fig. 1a
Fig. 1b
When installing the fan in an exposed outdoor location, use only light kits marked "Suitable for Use in Wet Locations."
The light source contained in this luminaire shall only be replaced by BAF or a qualified service agent or similar
qualified persons.
Wiring Harness
© 2024 DELTA T LLC. ALL RIGHTS RESERVED.
Light
Lower Cover
