GB
4. TROUBLESHOOTING
No satellite signal
Objects such as trees, bridges and large houses that are within the satellite's angle of
incidence will cause the signal to be lost. If the satellite signal is lost due to severe weather
conditions, the running programme of the TV (receiver) will freeze the picture or disappear.
When the weather conditions allow good reception again, the TV picture will be restored.
Is there dirt on the antenna?
Heavy soiling on the housing can lead to reception problems.
Is everything connected and switched on correctly?
Make sure that the TV and the receiver are connected properly and that the receiver is set
correctly for satellite reception. Are all cables connected or has another person accidentally
loosened the connections?
Satellite footprint
Satellites are positioned in fixed positions above the equator in orbit. To receive the TV
signals, the reception location must be within the footprint. Use the diagram to check whe-
ther your location is within the satellite's footprint. Reception interference may occur in the
peripheral areas of the footprint.
5. TECHNICAL DATA
Antenna type
Number of participants
LNB Type
Frequency band
Frequency range
LNB amplification
Receive power
Polarisation
Motor control
Inclination angle
Search angle
Temperature range
Dimensions mirror
Antenna dimensions
Weight antenna
Programmed satellite
Note:
Weight and dimensions are not the absolute exact values. Technical data may be changed at
any time without prior notice.
14
Parabolic antenna
1
Universal LNB
Ku Band
10.7 GHz bis 12.75 GHz
31 dBi @ 12.7 GHz
51 dBW
Vertikal / Horizontal
1.5-axis DC motor
23° to 43°
360°
-20° C to +70° C
380 mm (Ø)
450 x 430 mm (Ø/H)
ca. 4,2 kg
Astra 1 (19,2° Ost)
6. DISPOSAL INSTRUCTIONS
From the date of transposition of the European Directive 2012/19/EU into national
law, the following applies: Electrical and electronic equipment may not be
disposed of with household waste. The consumer is legally obliged to return
electrical and electronic equipment at the end of its life to the public collection
points set up for this purpose or to the point of sale. Details are regulated by the
respective national law. The symbol on the product, the instructions for use or the packaging
indicates these regulations. By recycling, material recovery or other forms of recovery of old
appliances, you are making an important contribution to the protection of our environment.
7. WARRANTY
Every Berger product is thoroughly inspected and tested before it leaves the factory.The
warranty begins with the purchase of the unit and lasts 24 months. Please prove this point
in time with the proof of purchase (sales slip, invoice, delivery note, etc.). Please keep these
documents in a safe place. If the unit needs to be repaired, take it to your specialist dealer or
send it there.
8. DISCLAIMER
Fritz Berger GmbH does not accept any liability or warranty for damage resulting from impro-
per installation, assembly and improper use of the product or failure to observe the operating
instructions and/or safety instructions.
9. EU DECLARATION OF CONFORMITY
With the CE mark, Fritz Berger GmbH declares that this product complies with the basic
requirements and other relevant regulations of the EU directive. The declaration of conformity
can be found in the appendix and can be requested at info@fritz-berger.de if required.
GB
15
