- The humidiy range is 40% to 80%. And the
default level is 55%.
- Press the arrows (3) to adjust the desired hu-
midity level. For every press the humidity % will
be adjusted by 5%.
- Once you have reached the desired humidity
%, stop pressing the buttons for 3 seconds.
The light indicator above will stop flashing and
the display (4) will show the ambient humidity
again.
- The appliance will run until the room's humidity
reaches 2% lower than the one chosen.
- When the ambient humidity is 2% higher than
the selected humidity level, the compressor will
start again.
TIMER FUNCTION:
- This function can be used when the dehumidi-
fier is on or in stand by mode:
- When the dehumidifier is on, the running time
of the compressor can be programmed.
- When the dehumidifier is off, it can be pro-
grammed to automatically turn on after the set
time.
- Press the timer button (6) to iniciate this func-
tion.
- The display screen (4) will show the time that is
selected.
- Adjust the desired time by pressing the arrows
(3) as many times as hours needed (1-24h).
Every press adjusts one hour.
- Once you reach the desired time, stop pressing
the button. After 3 seconds, the set time is
confirmed.
- The light indicator above will turn on.
- This function will be cancelled when the dehu-
midifier is manually switched on/off, or when
the water tank is full.
FAN SPEED:
- Select the desired fan speed (high or low) by
pressing the fan speed button (5).
- The pilot light will indicate which speed is
selected.
AIR OUTLET LEAF SWING:
- Press the swing button (2) to start this feature.
- To cancel this feature, press the swing botton
(2) again.
DRAINAGE (WATER TANK):
- When the water tank is full, the full tank light
indicator will turn on. The appliance also emits
a buzzing sound to alert the user.
- When the water tank is full, the operation will
stop.
- Proceed to remove the water tank. Place one
hand on each side of the depression areas to
gently remove the water tank.
- Pour the water out.
- Proceed to place the tank back into the appli-
ance to restart the dehumidifier.
DRAINAGE (CONTINUOUS DRAINAGE):
- If you do not want to empty the water tank ever-
ytime it gets full, you can connect the drainage
pipe provided (I) (inner diameter 10mm) to the
drainage outlet (G) to drain the water continu-
ously.
- The low end of the water pipe must be more
than 10cm lower than the height of the water
outlet.
- The end of the pipe cannot remain in water. It is
highly recommended to install it on a place that
allows the water to drain constantly.
- The water pipe must be kept smooth, otherwise
the water may not be drained properly.
ONCE THE APPLIANCE HAS BEEN USED:
- Stop the appliance pressing the on/off button
(1).
- Unplug the appliance from the mains.
- Clean the appliance.
CARRY HANDLES AND CASTORS:
- This appliance has handles on the side of the
body, which facilitates comfortable transport
(C).
- There are also four castors (D) to facilitate
the transportation of the appliance and avoid
injuries.
CLEANING
- Disconnect the appliance from the mains and
allow it to cool before undertaking any cleaning
task.
- Clean the electrical equipment and the mains
connection with a damp cloth and dry. DO
NOT IMMERSE IN WATER OR ANY OTHER
LIQUID.
