4 OPERATIONS
4.1 LED Overview
F
B
C
F
H
4.2 General Operation Mode and Test Mode
Push buttons and magnetic sensors have equivalent functions.
Push button
Magnetic sensor
Top
Right side
LED ON
LED Flashing
Power ON
Operation mode
Symbol /LED colour
LED
Function
~
A
Green LED
Power connected
B
Green LED
System active
Temperature within
C
Green LED
specified range
Heating active
D
Green LED
Forced heat active
Error detected
E
Red LED
Test mode active
Button or
System ON / OFF
F
top magnetic
Start: Push / swipe
sensor
Stop: Hold for 3 sec.
Button or right-
Forced heat
G
side magnetic
Start: Push / swipe
sensor
Stop: Hold for 3 sec.
H
Green LED
NA
NA
I
Green LED
NA
4.3 Activate Test Mode
Buttons
Start test mode by
Pushing
Toggle through test
Pushing
mode status by
Exit test mode at any
Pushing
time by
OJ cannot be held liable for any errors in catalogues, brochures or other printed material. OJ reserves the right to alter its products without notice. This also applies to products already on order, provided
that such alterations can be made without requiring subsequent changes in specifications already agreed. All trademarks in this material are the property of the respective companies. OJ and the OJ
logotype are trademarks of OJ Electronics A/S. All rights reserved.
~
A
D
E
G
G
I
LED
Flashes for 2 sec.
Flashes for 2 sec.
Test Mode
Function
Power connection
System active
Internal temp sensor
within specified range
External temp sensor 1
within specified range
NA
NA
Test mode active
Test mode
Start: Push / swipe
Stop: Hold for 3 sec.
Test mode
Start: Push / swipe
Toogle: Push / swipe
External temp sensor 2
within specified range
Sensor detects moist
Sensor does not detect
moist
Magnetic sensors
Swiping magnet
Swiping magnet on right-
button
side magnetic sensor
Holding magnet on top
magnetic sensor for 3
button for 3 sec.
sec.
The trademark is registered and belongs to OJ Electronics A/S · © 2019 OJ Electronics A/S
A
B
C
D
~
Idle State
Detecting State
Melting State
Afterrun State
Forced Heat
State
Moist testing
T1, Internal
temp. sensor
T2 –External
temp. sensor 1
T3 – External
temp. sensor 2
5 APPROVALS AND STANDARDS
5.1 Regulations
OJ Electronics A/S hereby declares that the product is in conformity with the
following directives of the European Parliament:
LVD - Low Voltage Directive
EMC - Electromagnetic Compatibility
RoHS - Restriction of the use of certain Hazardous Substances
WEEE - Waste Electrical and Electronic Equipment Directive
5.2 Standards and Approvals Applied
EU:
EN 60730-1, EN 60730-2-9
US:
UL 60730-1, UL 60730-2-9
Canada:
CAN/CSA E60730-1, CAN/CSA E60730-2-9
6 TECHNICAL SPECIFICATIONS
Purpose of control
Method of mounting.
Supply voltage
Max. pre-fuse
Enclosure rating
Nema Class
Wire size, terminals (power in/out)
Wire size, terminals (low voltage)
Cable size, MS 13.5 glands (signal,
Modbus)
Cable size, MS16 glands (mains, load)
Output voltage to remote control panel
Output voltage to heating element for
moist sensor
Max. Load/supply
Standby consumption
Ambient air humidity
Ambient operating temp.
Control temperature range
Storage/transport temp.
Dimensions
Weight
Control pollution degree
Overvoltage category
Type of action
Software class
Rated impulse voltage
Ball pressure temperature (TB)
Classification
E
H
I
Heating
Element
Moist
Relay
Electrical Ice and snow melting
Wall mounting
EU 3~ 240/400 VAC, ±10% 50 Hz
~ 230 VAC, ±10% 50 Hz
US/CAN 3~ 120/208 VAC, ±10% 60 Hz
3~ 277/480 VAC, ±10% 60 Hz
~ 120/240 VAC, ±10% 60 Hz
EU 32 A
US/CAN 30 A
IP 66
4X
0.75-10 mm
/ 20 AWG – 4 AWG
2
0.2-2.5 mm
2
/ 24 AWG – 12 AWG
5-12 mm
8-14 mm
28 VDC, 35mA
28 VDC, 125mA
EU 3x6900W at 3~ 230/400 VAC, 3x30A
6900W at ~ 230 VAC, 30A
US/CAN 3x8310W at 3~ 277/480 VAC, 3x30A
3x3600W at 3~ 120/208 VAC, 3x30A
3600W at ~ 120 VAC, 30A
7200W at ~ 240 VAC, 30A
approx. 1.25 W @ 230 VAC
10-95% non condensing
-50/+50°C (-58/+122 °F)
-30/+30°C (-22/+86 °F)
-50/+70°C (-58/+158 °F)
H/162, W/252, D/90 mm
H/6.38, W/9.92, D/3.40 in
1,500 g
2
III
1.B
A
4kV
125°C
Class I
