Wiring
5'
Remote control rcm 10
• 1x RJ 11 black at cable
Communication
• 2x RJ 45 black at cable :
rcc 02/03 / multi-units :
xtender, vt, vs, bsp, xcom
EN
The device must be installed in accordance with local standards and regulations in force.
FR
L'appareil doit être installé conformément aux normes et réglementations locales en vigueur.
DE
Das Gerät muss gemäß den geltenden örtlichen Normen und Vorschriften installiert werden.
El dispositivo debe instalarse de acuerdo con las normas y regulaciones locales vigentes.
ES
8
DC
RTC battery
remote entry
INPUT 0-600Voc / 900Voc (series)
48V
Temperature sensor
bts 01 / auxiliary
contacts remote
module arm 02
Earthing
• 1x RJ 11 black at cable
• 16mm
cable
2
• The solar generator
must be class II isolated
bus termination
PV connection
• 2.5-6mm
cable, Sunclix connector
2
Protection device (PV side)
• Switching device, max solar current :
2 x 13A (independent) / 1 x 26A (parallel) / 1 x 13A (serial)
• Overvoltage protection, SPD :
2 x 600Vdc (independent) / 1 x 600Vdc (parallel) / 1 x 900Vdc (series)
! 75V
*Bat+ connection
Battery connection
(provided)
• 50mm
cable M8/M10, 8Nm
2
fusible
ceramic
washer
BAT+, M8
washer
bolt
Protection device (battery side)
M8 x 30
135A
M10 cable
M8
T10
BAT-, M10
Lithium batteries communication
BMS CAN
xcom CAN
CAN
Li
9
