- Page 1 120 swiss made power...
- Page 2 See more about our warranty conditions Está a punto de instalar y de utilizar un equipo de alta gama que desempeñará on our website studer-innotec.com/studer-care una función esencial en la gestión de energía de su sistema con almacenamiento. El variostring (vs) es un controlador de carga solar MPPT. Conectado a una batería designed and manufactured y a paneles fotovoltaicos, el vs recarga automáticamente las baterías de manera...
- Page 3 Studer disclaims all responsibility and liability for damage, costs or losses resulting from an installation that does not comply with the instructions, a faulty operation or inadequate maintenance. The use of studer equipment is in any case under the responsibility of the customer.
- Page 4 Mounting and installation Storage and content Fixing and dimensions 60°C 256mm -20°C min. 200mm min. 50mm Mounting place min. 200mm 7.5kg 322mm 133mm...
- Page 5 Wiring PV connection 5’ • 2.5-6mm cable, Sunclix connector Protection device (PV side) • Switching device, max solar current : 2 x 13A (independent) / 1 x 26A (parallel) / 1 x 13A (serial) RTC battery • Overvoltage protection, SPD : 2 x 600Vdc (independent) / 1 x 600Vdc (parallel) / 1 x 900Vdc (series) remote entry INPUT 0-600Voc / 900Voc (series)
- Page 6 Multi units and power up Display Display system on – the device is off Dual isolated string MPPT solar charger controller blink – error, check the manual Status Charge [A] Error Charge on – bulk Night 1x – oating 2x – absorption Floating 1x 3x - equalization Absorption 2x...
- Page 7 Con guring the variostring Technical data Battery voltage (check manual) Lead-acid • Con gure charge auto Series pro le according to manufacturer Independent Parallel Lithium (comm BMS, xcom CAN) off • Check compatibility list and xcom CAN manual Spare 5-6 Others : NiCd, Activate DIP switches...
- Page 8 Maintenance and recycling Maintenance and recycling Except for the periodic check of the connections (tightening, general condition), the variostring does not require any particular maintenance. To dispose of this product, please use the service for the collection of electrical waste and observe all obligations in force in the place of purchase.
- Page 9 Serial Number : Installed by : Date : Signature : Call our specialists +41 27 205 60 80 or visit studer-innotec.com/support Studer Innotec SA rue des Casernes 57 1950 Sion, Switzerland info@studer-innotec.com © All rights reserved Studer Innnotec SA – V1.3...
