Assembly Guide
Step9:
Accessories and Tools:
Use 2 M4×14 screws to secure the controller to the desktop.
(To prevent scratching the desktop, place soft items such
as a carpet on the floor before installation,
and assemble the desktop with the reverse side facing up.)
R-2.5mm hex wrench
O-M4×14 screws x2
O
Operating Guide
*Initialization Procedure
Hold the
button to raise the desk until it reaches the highest point.
Hold the
button to lower the desk until it reaches the lowest point.
Press
or
briefly to make the desk move a small distance for incremental adjustments.
*Up and Down Button Operations
Hold the
button to raise the desk until it reaches the highest point.
Hold the
button to lower the desk until it reaches the lowest point.
Press
or
briefly to make the desk move a small distance for incremental adjustments.
*Position Storage and Memory Operation
The controller can store up to 4 different height settings.
Memory positions remain effective even after a power outage.
To store a position, when at the desired point, press the "M" button.
The digital display will show "S-" with the "-" blinking.
Press the "1-4" buttons to save the current position to the corresponding number.
*Height Limits Setting
The system supports setting height limits for the desk.
To set the current height as the desk limit, simultaneously press and hold
When the desk is in the upper half of its range, it limits the upper position, and in the lower half, it limits the lowest position.
To cancel the height limit:
Method 1: Initialize the system; the height limit is canceled.
Method 2: Bring the desk to the limit height (upper or lower),
then simultaneously press and hold
+
or 5 seconds. A beep will indicate successful cancellation.
5
Step10:
Insert the lifting leg cable and power cable into
the controller together.
K
H
Up button
Down button
Digital display screen
M
Settings button
1
Memory button
2
Memory button
3
Memory button
4
Memory button
+
for 5 seconds. A beep will sound, indicating successful limit position storage.
*Lock and Unlock
To lock the system, simultaneously press and hold "M" +
To unlock, repeat the process until the display returns to normal numeric values.
*Factory Reset
When changing desk legs or when parameters need to be restored to factory settings, simultaneously
press and hold for
J
*Timer Operation
Press "1" + "3" to set the timer. Initially, the controller displays 0.0h. Adjust the timer using
the controller will automatically exit after 2 seconds, and a blinking decimal point indicates an active timer. When the set time is reached,
the buzzer will sound five times, and the controller will automatically wake up.
*Internal Parameters and Installation Distance Setting
Hold the "M" button for 15 seconds to enter the settings interface, displaying "S-x" with "x" blinking.
Press "M" to enter the parameter settings for the corresponding group, and use
0 represents metric display, and 1 represents imperial display. After setting parameters, press "M" to return to the operating interface.
Technical Specifications
Operating Speed
Code Handling
Code
E05
E07
HOT
E18
Motor 1 is experiencing excessive load, overloaded.
for 5 seconds until the digital display shows "Loc."
10 seconds to hear a long beep, indicating a return to factory settings and a forced initialization.
or
Input Voltage
Output Voltage
Lifting Capacity
Height Range
Duty Cycle
Interpretation
Halt and display when encountering obstacles.
Protection activates when the main
power is running below 20V.
Power temperature is too high,
or the system has been running for more than
or let the system rest for 18 minutes before restarting.
2 minutes within 18 minutes.
or
, with increments of 0.5 hours. After setting,
to switch between parameter groups. In "S-1,"
AC 100~240V
29 VDC
60 kg
72 cm - 120 cm
20 mm/s
Run 2 min, Rest 18 min
Operation
Release the button and restart.
Repower on.
Wait for the power temperature to decrease,
Reduce the load
6
